Ji Xiang Song - IMO 9608922

Name

JI XIANG SONG

Type

General dry cargo ship / Container ship

IMO-number

9608922

Call sign

BOEC

Flag

China

Port of registry

Guangzhou

GT

20.684 t

DWT

27.351,6 t

NT

11.468 t

Number of 20ft containers

On deck: 765

In hold: 606

Total: 1.371

Length

179,50 m overall

169,50 m between perpendiculars

Breadth

27,20 m moulded

Draught

10,20 m

Forecastle

55,70 m

Poop

18,60 m

Freeboard

4.025 mm

Depth

14,50 m moulded

Speed

15,1 knots

Built

2011

Date of completion

22.12.2011

Builder

CSSC Guangzhou Huangpu Shipbuilding Co., Ltd.
China

Yard number

2317

Hull material

Steel

Bulkheads

8

Main engine

1x 6S50ME-C8 - 6 cylinder 500 x 2.000 mm diesel engine - 8.250 kW at 124,0 rpm

Built: 01.08.2011

Builder: Hu Dong Heavy Machinery Co.,Ltd.

Propellers

1

Generators

3x FE 547B-8 main diesel generatorsets each 700 kVA - 450 Volt

Number of holds

5

Hold capacity

Hold 1: Bales 1.800,72 m³ / Grain: 1.936,26 m³
Hold 2: Bales 9.761,50 m³ / Grain: 10.496,24 m³
Hold 3: Bales 9.086,78 m³ / Grain: 9.770,74 m³
Hold 4: Bales 9.086,79 m³ / Grain: 9.770,74 m³
Hold 5: Bales 7.853,83 m³ / Grain: 8.444,98 m³

Number of hatches

3x Hatch: 25,74 × 23,60 m

1x Hatch: 9,80×11,10

1x Hatch: 18,32×15,67 + 23,60×15,87 m

Water ballast

10.770,77 m³

Lifting equipment

1x Crane - SWL 1,6 t

Cargo gear

1x Crane - SWL 40,0 t

2x Cranes - SWL 45,0 t each

2x Cranes - SWL 90,0 t each

Manager

COSCO Shipping Co., Ltd.
Guangzhou
China

Operator

COSCO Shipping Co., Ltd.

Registered owner

COSCO Shipping Co., Ltd.
Guangzhou
China

Last update

03 July 2013
