Westerschelde 10 June 2016 |
 |
 |
 |
||
| Antwerpen 10/01/14 | Westerschelde 02/09/16 | Westerschelde 09/04/18 | ||
|
Name |
SCOT RANGER |
|
Type |
General cargo ship - Strengthened for heavy cargo Box shaped singledecker |
|
IMO-number |
9138769 |
|
Call sign |
MZKS5 |
|
Flag |
United Kingdom |
|
Port of registry |
Inverness |
|
Previous flags |
1997 - 2000 Bahamas, Nassau |
|
GT |
2.260 t |
|
DWT |
Summer: 3.418,86 t Winter: 3.301,18 t |
|
DWCC |
3.200 t |
|
NT |
1.128 t |
|
Length |
84,90 m overall 80,20 m between perpendiculars |
|
Breadth |
12,70 m extreme 12,60 m moulded |
|
Draught |
Summer: 5,11 m Winter: 5,00 m |
|
Air draft |
25,50 m in ballast |
|
Forecastle |
8,40 m |
|
Depth |
6,70 m moulded |
|
Speed |
12,0 knots |
|
Built |
1997 |
|
Keel laid |
05/02/1996 |
|
Launch date |
10/1996 |
|
Date of completion |
27/03/1997 |
|
Builder |
Yorkshire Dry Dock Co. Ltd. Lime Street Hull, North H. HU8 7AG United Kingdom |
|
Yard number |
341 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double hull Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
5 |
|
Number of decks |
2 |
|
Main engine |
1x MAK 9M20 - 4 stroke 9 cylinder 200 x 300 mm combustion engine 1.500 kW / 2.099 hp at 1.000 rpm Year of manufacture: 1996 Manufacturer: Krupp Mak Maschinenbau GmbH Falckensteiner Str. 2 24159 Kiel Federal Republic of Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 247 rpm |
|
Electric installations |
2x Plants each 380/220 V - 100 kVA 1x Plant 380 V - 113 kVA 1x Plant 380 V - 25 kVA |
|
Shaft generator |
1x 113 kVA |
|
Generators |
2x Cummins main diesel generatorsets each 100 kVA / 80 kW |
|
Emergency generator |
1x Perkins diesel generatorset 25 kVA / 20 kW |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar |
|
Bow thruster |
1x Fixed pitch propeller KAMEWA - 200 kW, forward |
|
Number of holds |
1x Box type 53,40 x 10,20 x 7,60 m |
|
Hold capacity |
Grain & bales: 4.131 m³ / 145.910 ft³ |
|
Timber fitted capacity |
4.000 |
|
Number of hatches |
1 53,40 X 10,20 m |
|
Max permitted loads |
Tank top: 12 t/m² Hatch covers: 1,55 t/m² |
|
Tank capacities |
Ballast water: 1.132 m³ Fuel: 140,0 t Fresh water: 30,0 t |
|
Anchor equipment |
3x Anchors weight each 1.740 kg Chain length: 440,00 m |
|
Manager |
Scotline Ltd. 75, Main Road Gidea Park Romford ,RM2 5EL Essex United Kingdom |
|
Operator |
Scotline |
|
Registered owner |
Scot Ranger Shipping Ltd. 41, Culduthel Road Inverness ,IV2 4AT Highland United Kingdom |
|
Renamed |
2019 - 2022 Rova Antigua & Bermuda, St. John’s - Call sign: V2HE4 Owner & manager: Rova Shipping GmbH & Co KG, Varel - Germany 2023 Sky Ranger Republic of Panama, Panama City - Call sign: 3E4116 Owner: Sky Ranger Shipping Inc. Manager: Feyz Group Inc., Istanbul - Turkey |
|
Latest data adjustment |
01 December 2023 |
