Westerschelde 18 August 2018 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 18/08/18 | Westerschelde 18/08/18 | Malaga, Spain 21/02/14 | Gent, Belgium10/05/14 | Gent, Belgium 10/05/14 | Vlissingen 17/08/20 |
|
Name |
DAMSTERDIJK |
|
Type |
Multi-purpose dry cargo ship - Strengthened for heavy cargo - Singledecker Gearless box singledecker |
|
IMO-number |
9346665 |
|
Call sign |
PHKS |
|
Flag |
The Netherlands |
|
Port of registry |
Groningen |
|
GT |
2.984 t |
|
DWT |
4.891 t |
|
DWCC |
Winter: 4.500 t Summer: 4.600 t |
|
NT |
1.598 t |
|
Number of 20ft containers |
On deck: 38 |
|
Length |
89,95 m overall 84,94 m registered |
|
Breadth |
14,40 m moulded |
|
Draught |
Summer: 6,22 m Winter: 6,09 m |
|
Air draft |
Keel/mast in ballast: 22,50 m Keel/mast down: 19,00 m |
|
Depth |
7,85 m moulded |
|
Speed |
11,5 knots |
|
Built |
2007 |
|
Keel laid |
21/11/2005 |
|
Launch date |
17/05/2006 |
|
Date of completion |
11/09/2007 |
|
Builder |
Chowgule & Company Private Ltd. Shipbuilding Division Loutulim Near Borim Bridge Loutulim Road Loutulim, 403718 Goa Republic of India |
|
Yard number |
C0173 |
|
Hull material |
Shipbuilding steel (standard) Higher tensile steel |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
2 |
|
Movable bulkhead |
2x Bulkheads / 8 positions |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M25 - 4 stroke single acting 6 cylinder 255 x 400 mm combustion engine 1.980 kW / 2.700 hp at 750 rpm Year of manufacture: 2006 Manufacturer: Caterpillar Motoren GmbH & Co. KG Falckensteiner Str. 2 24159 Kiel Federal Republic of Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 158 rpm |
|
Boilers |
Water heater, oil fired - 4,0 bar Heating Surface: 8,47 m² Manufacturer: Viessmann Werke Berlin GmbH Kanalstr. 13 12357 Berlin Federal Republic of Germany |
|
Electric installations |
1x Plant 415 V - 205 kVA 1x Plant 415 V - 375 kVA 1x Plant 415 V - 205 kVA |
|
Shaft generator |
1x 375 kVA |
|
Generators |
1x Main diesel generatorset 205 kVA |
|
Emergency generator |
1x Diesel generatorset 205 kVA |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster 250 kW, forward |
|
Number of holds |
1x Box sid 62,30 x 11,70 x 8,12 m Full box over 50,28 x 11,70 x 8,10 m |
|
Cargo capacity |
205.471 ft³ / 5.728 m³ |
|
Number of hatches |
1 62,30 x 11,70 m |
|
Hatch cover type |
10x Pontoon |
|
Strength |
Tanktop: 15 t/m², suitable for heavy cargo Hatchcover: 1,6 t/m² |
|
Anchor equipment |
3x Anchors weight each 2.100 kg Chain length: 440,00 m |
|
Lift equipment |
1x Gantry crane for pontoons |
|
Cargo gear |
Gearless |
|
ISM & commercial manager |
SCG Management B.V. Eenrumermaar 2 9735 AD Groningen The Netherlands |
|
Previous manager |
Navigia Shipmanagement B.V.,29723 AZ Groningen - The Netherlands |
|
Registered owner |
Damsterdijk 2.0 B.V. Care of SCG Management BV Eenrumermaar 2 9735 AD Groningen The Netherlands |
|
Previous owners |
2007 - 08.2012 Beheermaatschappij Damsterdijk B.V., Groningen - The Netherlands 08/2012 - 07/2017 Beheermaatschappij MS "DAMSTERDIJK II" B.V.; 9744 DX Groningen - The Netherlands |
|
Latest data adjustment |
15 February 2022 |
