Name |
DAMINA |
|
Type |
Multi-purpose dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo - singledecker |
|
IMO-number |
9433365 |
|
Call sign |
V2EW2 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
GT |
4.723 t |
|
DWT |
Summer: 7.571 incl. bulkheads |
|
DWCC |
Summer: 7.200 t Winter: 6.900 t |
|
NT |
2.724 t |
|
Number of 20ft containers |
265 |
|
Length |
116,08 m overall 109,78 m between perpendiculars |
|
Breadth |
15,90 m extreme 15,80 m moulded |
|
Draught |
Summer: 6,38 m |
|
Air draft |
21,78 m ballast |
|
Depth |
8,90 m moulded |
|
Speed |
13,5 knots |
|
Built |
2010 |
|
Keel laid |
01/10/2009 |
|
Launch date |
10/07/2009 |
|
Date of completion |
17/03/2010 |
|
Builder |
Bodewes Shipyards B.V. Hoogzand The netherlands |
|
Yard number |
773 |
|
Hull material |
Steel |
|
Movable bulkheads |
1x Movable bulkhead - Various positions |
|
Main engine |
1x MaK 6M32C - 4 stroke 6 cylinder 320 x 480 mm combustion engine 2.999 kW at 600 rpm Builder: Caterpillar Motoren GmbH & Co.KG, Kiel - Germany |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired |
|
Shaft generator |
1x 435 kW |
|
Generators |
2x Sisu 84.494 CTAG-4 V main diesel generatorsets each 250 kW |
|
Emergency generator |
1x Sisu 47.492 CTAG-4 V diesel generatorset |
|
Bow thruster |
1x 300 kW |
|
Number of holds |
2x Bow sid Hold 1: 38,25 x 13,25 x 9,00 m Hold 2: 44,25 x 13,25 x 9,00 m |
|
Cargo hold capacity |
9.440 m³ / 333.400 ft³ |
|
Number of hatches |
2 Hatch 1: 38,25 x 13,25 m Hatch 2: 44,25 x 13,25 m |
|
Hatch cover type |
Pontoon type |
|
Max. permitted loads |
Tanktop: 15,0 t/m² On deck: 2,60 t/m² |
|
Tank capacities |
Ballast: 3.120,12 m³ |
|
Anchor equipment |
Length: 467,50 m Diameter: 40 mm |
|
Manager |
Reederei Erwin Strahlmann GmbH & Co. KG Schleusenstraße 10 25541 Brunsbüttel Germany |
|
Operator |
R.E.S. Chartering GmbH Fuhlentwiete 10 20355 Hamburg Germany |
|
Previous owners |
LAPPAN Shipping & Trading GmbH & Co. KG |
|
Reanmed |
2021 Anne G.D. Luxembourg, Luxembourg - Call sign: LXBQ Owner: Vertom Anne GmbH & Co KG - Germany Manager: Vertom Bereederungs GmbH - Germany |
|
Latest data adjustment |
13 August 2022 |
