Westerschelde 12 July 2014 |
|
Name |
POAVOSA ACE |
|
Type |
Bulk carrier - Strengthened for heavy cargo loading |
|
IMO-number |
9668362 |
|
Call sign |
3EWV5 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
17.027 t |
|
DWT |
Summer: 28.208 t |
|
NT |
10.108 t |
|
Length |
169,37 m overall |
|
Breadth |
27,20 m moulded |
|
Draught |
Summer: 9,82 m |
|
Moulded L x B x D |
160,40 x 27,20 x 13,60 m |
|
Registered L x B x D |
161,21 x 27,20 x 13,60 m |
|
Freeboard |
3.825 mm |
|
Speed |
15,8 knots |
|
Built |
2013 |
|
Keel laid |
16.11.2010 |
|
Launch date |
26.07.2013 |
|
Date of completion |
17.09.2013 |
|
Builder |
I-S Shipyard Co., LTD. |
|
Yard number |
A056 |
|
Hull material |
Steel |
|
Main engine |
1x 2 stroke single acting 6 cylinder 420 x 1.764 mm diesel engine - 5.850 kW at 129,0 rpm Manufacturer: Makita Corporation |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 420 mm |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary vertical boiler - 8,0 bar Evaporation: 1,95 t/h Manufacturer: Miura Co., Ltd. |
|
Generators |
4x generators - 1.715 kVA |
|
Cargo hold capacity |
Bales: 35.742 m³ Grain: 37.320 m³ |
|
Tank capacities |
Fuel oil: 1.538 m³ Fresh water: 262 m³ Water ballast: 7.845 m³ |
|
Manager |
Wisdom Marine Lines S.A. |
|
Operator |
Wisdom Line |
|
Registered owner |
Poavosa Navigation S.A. |
|
Latest data adjustment |
19 August 2014 |
