Westerschelde 24 March 2018 |
|
Name |
PLUTO |
|
Type |
Bulk carrier |
|
IMO-number |
9432531 |
|
Call sign |
D5FC4 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
19.785 t registered |
|
DWT |
Summer: 32.092 t |
|
NT |
10.395 t registered |
|
Length |
175,53 m overall |
|
Breadth |
29,40 m moulded |
|
Draught |
Max: 9,64 m |
|
Moulded L x B x D |
167,00 x 29,40 x 13,70 m |
|
Registered L x B x D |
167,76 x 29,40 x 13,70 m |
|
Freeboard |
Summer: 4.105 mm |
|
Depth |
13,70 m moulded |
|
Speed |
Max: 16,1 knots |
|
Built |
2014 |
|
Keel laid |
20/12/2011 |
|
Launch date |
17/02/2014 |
|
Date of completion |
17/04/2014 |
|
Builder |
Hakodate Dock Co., Ltd. Japan |
|
Yard number |
840 |
|
Hull material |
Steel |
|
Hull type |
Double hull construction applied to all cargo holds |
|
Main engine |
1x Mitsubishi 6UEC45LSE - 2 stroke single acting 6 cylinder 450 x1.840 mm combustion engine 6.840 kW at 129,0 rpm Manufacturer: Kobe Diesel Co., Ltd. |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 430 mm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary vertical boiler - 7,0 bat Evaporation: 2,30 t/h Manufacturer: Osaka Boiler Mfg., Co., Ltd. |
|
Generators |
3x Generatorsets total 1.080 kVA |
|
Cargo hold capacity |
Bale: 39.272 m³ Grain: 40.503 m³ |
|
Tank capacities |
Fuel oil: 1.387 m³ Fresh water: 200 m³ |
|
Cargo gear |
4x Deck cranes - SWL 30,0 t each |
|
Crew size |
23 |
|
Manager |
Johann M.K. Blumenthal GmbH & Co. Kg Palmaille 120 22767 Hamburg Germany |
|
Registered owner |
Epsilon Shipholding Ltd. |
|
Latest data adjustment |
12 May 2020 |
