Westerschelde 22 August 2018 |
 |
 |
 |
 |
|||
| Antwerpen 31/10/14 | Westerschelde 19/05/17 | Westerschelde 19/05/17 | Westerschelde 11/07/17 | |||
|
Name |
MARLEY |
|
Previous names |
Launch as: 1995 Annlen G 1995 - 11/1996 Duisburg 11/1996 - 10/2008 Annlen G 10/2008 - 11/2013 Ardesco |
|
Type |
Multi-purpose dry cargo ship - Single hold Vessel is grain fitted two moveable bulkheads, steel floored, box shapes |
|
IMO-number |
9116814 |
|
Call sign |
ONHT |
|
Flag |
Belgium |
|
Port of registry |
Antwerpen |
|
|
Slovakia - Call sign: OMRC 2011 - 2013 Antigua & Barbuda, St. John’s - Call sign: V2FW2 |
|
GT |
2.061 t |
|
DWT |
Summer: 3.002 t |
|
DWCC |
Summer: 2.900 t Winter: 2.800 t |
|
NT |
1.161 t |
|
Displacement |
Summer: 2.903 t |
|
Light ship |
1.089,17 t |
|
Number of 20ft containers |
In hold: 78 On deck: 40 Total: 118 |
|
Reefer capacity |
6 |
|
Length |
88,48 m overall 84,68 m between perpendiculars |
|
Breadth |
11,35 m moulded 11,40 m extreme |
|
Draught |
Summer: 4,94 m Winter: 4,84 m |
|
Keel to mat end |
23,00 m |
|
Air draft |
10,50 m bridge down 15,50 m bridge up |
|
Freeboard |
Summer: 1.466 mm |
|
Depth |
6,42 m moulded |
|
Speed |
Max: 11,5 knots Service: 9,5 Knots |
|
Built |
1995 |
|
Date of completion |
05/1995 |
|
Builder |
Slovenske Lodenice A.S. 94525 Komarno Slovakia Republic |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight bulkheads |
4 |
|
Movable bulkheads |
2x Moveable bulkheads, full hold height, 10 positions |
|
Number of decks |
1 |
|
Main engine |
1x Deutz MWM SBV8M628 combustion engine engine 1.125 kW / 1.529 hp Builder: Deutz-MWM Motorenwerke AG, Mannheim - Germany |
|
Propellers |
1 |
|
Boiler |
1x Auxiliary boiler, oil/gas fired |
|
Generators |
3x Deutz MWM TD 226-6 main diesel generatorsets 1x Volvo Penta TMD 102 A diesel generatorset |
|
Bow thruster |
1x Jastram model BU40 - 175 kW |
|
Number of holds |
1x Box Dimension: 57,50 x 9,01 x 8,06 m |
|
Total hold capacity |
Grain: 4.091 m³ / 144.362 ft³ Bale: 4.078 m³ / 143.903 ft³ |
|
Hold ventilation |
Electrical ventilation - 6 airchanges/hour |
|
Number of hatches |
1 Dimension: 57,50 x 9,00 m |
|
Hatch type |
Kvaerner multi-fold crocodile |
|
Strength |
Tanktop: 12,0 t/m² Hatch cover: 1,2 t/m² |
|
Tank capacities |
Ballast water: 1.181 m³ Gas oil: 135 m³ Fresh water: 23,40 m³ |
|
Manager |
Boeckmans België Van Meterenkaai 1 2000 Antwerpen Belgium |
|
Owner |
NV Rederij Marlin Care of Boeckmans Belgie NV Van Meterenkaai 1 2000 Antwerpen Belgium |
|
Latest data adjustment |
18 September 2023 |
