Westerschelde 17 March 2019 |
 |
 |
|
| Antwerpen 09/04/15 | Westerschelde 28/08/20 |
|
Name |
FAST SUS |
|
Previous names |
1996 - 09/1999 Aletis |
|
Type |
General cargo ship - heavycargo |
|
IMO-number |
9136096 |
|
Belgian register number |
01 00651 2007 |
|
Call sign |
ONEO |
|
Flag |
Belgium |
|
Port of registry |
Antwerpen |
|
Previous flag |
04/1996 - 04/2007 The Netherlands, Puttershoek - Call sign: PCVZ |
|
GT |
2.055 t |
|
DWT |
Summer: 3.234 t |
|
DWCC |
Summer: 3.135 t Winter: 3.030 t |
|
NT |
1.117 t |
|
Number of 20ft containers |
In hold 76 On deck: 40 Total: 116 |
|
Length |
89,98 m overall 84,98 m between perpendiculars |
|
Breadth |
12,50 m extreme |
|
Draught |
Summer: 4,65 m fully laden Winter: 4,55 m fully laden |
|
Keel to mast end |
19,80 m |
|
Air draft |
11,00 m with masts folded |
|
Freeboard |
1.180 mm |
|
Depth |
6,00 m moulded |
|
Speed |
12,0 knots |
|
Built |
1996 |
|
Launch date |
15/03/1996 |
|
Date of completion |
12/04/1996 |
|
Builder |
Scheepswerf & Machinefabriek Barkmeijer Stroobos B.V. Stroobos The Netherlands |
|
Yard number |
282 |
|
Hull material |
Steel |
|
Watertight compartments |
4 |
|
Movable bulkhead |
2x Movable bulkhead in 4 positions |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M20 - 4 stroke single acting 8 cylinder 200 x 300 mm combustion engine 1.000 kW / 1.358 hp at 900 rpm Built: 1995 Builder: Krupp MaK Maschinenbau GmbH, Kiel - German Federal Republic |
|
Propellers |
1x Fixed pitch propeller - aft at 227 rpm |
|
Electric installations |
Power voltage: 380 V Lighting voltage: 220 V Frequency: 50 Hz |
|
Generators |
2x Diesel generatorsets each 112 kVA - 90 kW - 150 hp |
|
Emergency generator |
1x Diesel generatorset 66 kVA - 53 kW - 72 hp |
|
Bow thruster |
1x Veth Type VT150 output 220 kW |
|
Number of holds |
1 Dimensions: 63,00 x 10,20 x 6,43 m |
|
Hold capacity |
Grain: 4.086 m³ / 144.308 ft³ with bulkheads Bale: 4.043,71 / 142.803 ft³ with bulkheads |
|
Number of hatches |
1 63,00 x 10,20 m |
|
Hatch type |
Pontoon type |
|
Max. permitted loads |
Tank top: 12 t/m² Hatch covers: 1,6 t/m² |
|
Fuel capacity |
Gas oil: 177 m³ Fresh water: 58 m³ Lub oil: 3,0 m³ Ballast: 1.501 m³ |
|
ISM & commercial manager |
Fast Baltic SP Zoo ul Bytomska 7 70-603 Szczecin Poland |
|
Previous managers |
04/1996 - 09/1999 Rederij de Vrij, Puttershoek - The Netherlands 09/1999 - 04/2007 Soetermeer, Fekkes' Cargadoorskantoor N.V., Rotterdam - The Netherlands |
|
Registered owner |
Fast Lines Belgium N.V. Ernest Van Dijckkaai 15/17 B-2000 Antwerpen Belgium |
|
Previous names & owners |
04/1996 - 04/2007 Aletis - Rederij de Vrij, Puttershoek - The Netherlands |
|
Latest data adjustment |
23 September 2022 |
