Westerschelde 18 April 2019 |
 |
 |
 |
 |
|||
| Westerschelde 13/07/18 | Antwerpen 07/08/17 | Antwerpen 07/08/17 | Antwerpen 28/09/14 |
|
Name |
FAST SAM |
|
Previous names |
1994 - 11/1999 Sprinter |
|
Type |
General dry cargo ship |
|
IMO-number |
9085455 |
|
Call sign |
ONEJ |
|
Flag |
Belgium |
|
Port of registry |
Antwerpen |
|
Previous flag |
1994 - 04/2005 Cyprus, Limassol - Call sign: P3GR5 04/2005 - 02/2007 The Netherlands, Puttershoek - Call sign: PHCS |
|
GT |
1.983 t |
|
DWT |
Summer: 3.230 t |
|
DWCC |
Summer: 3.204 t Winter: 3.098 t |
|
NT |
1.061 t |
|
Number of 20ft containers |
In hold: 76 + 40 TEU Total: 116 |
|
Length |
89,99 m overall 84,98 m between perpendiculars |
|
Breadth |
12,50 m |
|
Draught |
Summer: 4,54 m fully laden Winter: 4,50 m fully laden |
|
Air draft |
7,00 m |
|
Freeboard |
Summer: 1.170 mm |
|
Depth |
6,00 m |
|
Speed |
10,5 knots |
|
Built |
1994 |
|
Keel laid |
04/1993 |
|
Launch date |
22/10/1993 |
|
Date of completion |
03/01/1994 |
|
Builder |
Barkmeijer Stroobos B.V. Stroobos The Netherlands |
|
Yard number |
269 |
|
Hull material |
Steel |
|
Watertight compartments |
5 |
|
Movable bulkhead |
2x Movable bulkhead in 5 positions |
|
Continuous decks |
1 |
|
Main engine |
1x ABC 6DZC- 4 stroke single acting 6 cylinder 256 x 310 mm combustion engine 1.325 kW / 1.801 hp at 1.000 rpm Built: 1993 Builder: Anglo Belgian Corporation NV Wiedauwkaai 43 900 Gent Belgium |
|
Rudder |
1x Flap type |
|
Propelling system |
1x Screw propeller solid - aft at 220 rpm |
|
Electric installations |
Power voltage: 380 V Lighting voltage: 220 V Frequency: 50 Hz |
|
Generators |
1x Diesel generatorset 47 kVA - 38 kW - 52 hp 2x Diesel generatorsets each 112 kVA - 90 kW - 114 hp |
|
Bow thruster |
1x Veth type VT 150 output 185 kW |
|
Number of holds |
1 61,80 x 10,20 m x 6,23 m |
|
Total capacity of holds |
Grain/Bales: 3.903 m³ / 137.800 ft³ |
|
Number of hatches |
1 61,80 x 10,20 m |
|
Hatches type |
Pontoon type 10 sections |
|
Max. permitted loads |
Tanktop: 12,0 t/m² Hatch covers: 1,5 t/m² |
|
Tank capacities |
Gas oil: 188 m³ Fresh water: 54 m³ Lub oil: 3,0 m³ Ballast: 1.490 m³ |
|
ISM & commercial manager |
Fast Baltic Sp. z o.o. Ul. Bytomska 7 70-603 Szczecin Poland |
|
Previous managers |
1994 -02.2007 Soetermeer, Fekkes' Cargadoorskantoor N.V., Rotterdam - The Netherlands |
|
Owner |
Fast Lines Belgium NV Ernest Van Dijckkaai 15/17 2000 Antwerpen Belgium |
|
Previous names & owners |
1994 - 1999 Sprinter - Saligot Shipping Co. Ltd., Limassol - Cyprus 1999 - 04/2005 Fast Sam - Saligot Shipping Co. Ltd., Limassol - Cyprus 04/2005 - 02/2007 Fast Sam - J.J. de Vrij & Co. C.V., Puttershoek - The Netherlands |
|
Latest data adjustment |
26 April 2022 |
