Westerschelde 15 April 2017 |
 |
 |
 |
||
| Westerschelde 15/04/17 | Antwerpen 07/05/15 | Antwerpen 07/05/15 | ||
|
Name |
ANNEGRET |
|
Type |
General cargo ship - Strengthened for heavy cargo - Heavy lift ship |
|
IMO-number |
9147710 |
|
Call sign |
V2LL |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
GT |
8.397 t Suez: 8.572,53 t |
|
DWT |
Summer: 9.359 t |
|
NT |
4.178 t Suez: 6.915,35 t Panama: 7.636 t |
|
Displacement |
Summer: 14.980 t |
|
Length |
151,66 m overall 143,32 m registered |
|
Breadth |
20,40 m moulded 21,02 m overall |
|
Draught |
Summer: 7,84 m |
|
Freeboard |
Summer: 2.179 mm |
|
Depth |
10,50 m moulded |
|
Speed |
19,5 knots |
|
Built |
2000 |
|
Keel laid |
28/02/1996 |
|
Launch date |
29/01/2000 |
|
Date of completion |
18/03/2000 |
|
Builder |
J.J. Sietas KG Schiffswerft GmbH & Co. Neuenfelder Fährdeich 88 21129 Hamburg Federal Republic of Germany |
|
Yard number |
1162 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
5 |
|
Continuous decks |
2 |
|
Main engine |
1x MAN B&W 9L48/60 - 4 stroke 9 cylinder 480 x 600 mm combustion engine 9.450 kW at 500 rpm Reduction power: 4.995 kWYear of manufacture: 1999 Manufacturer: MAN B&W Diesel GmbH Stadtbachstr. 1 86153 Augsburg Federal Republic of Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 140 rpm |
|
Boilers |
1x Thermal oil heater, oil fired - 10,0 bar Heating surface: 35,0 m² 1x Thermal oil heater, exhaust gas heated - 10,0 bar Heating surface: 157,5 m² Year of manufacture: 1999 Manufacturer: PWT Prozess-Wärmeträgertechnik GmbH Justus-von-Liebig-Ring 4-6 25451 Quickborn Federal Republic of Germany |
|
Electric installations |
3x Plants each 380/220 V - 380 kVA 1x Plant 380 V - 1.250 kVA 1x Plant 380 V - 430 kVA |
|
Shaft generator |
1x 1.250 kVA |
|
Generators |
3x Main diesel generatorsets each 380 kVA |
|
Emergency generator |
1x Diesel generatorset 430 kVA |
|
Compressed air receivers |
2x Receivers each 1.000 litres - 30,0 bar 1x Receiver 475 litres - 11,0 bar |
|
Bow thruster |
1x LIPS fixed pitch propeller - 750 kW / 1.020 hp, forward |
|
Number of holds |
1 Dimension: 82,90 x 15,80 x 10,97m |
|
Hold capacity |
Grain: 14.000 m³ Bales: 13.604 m³ |
|
Number of hatches |
1 |
|
Hatch type |
MacGregor hydraulic operated combined folding type and lift and roll type |
|
Free deck space |
2.120 m² Dimensions: 124,00 x 20,50 m |
|
Tank capacities |
Fuel oil: 1.093,29 m³ Gas oil: 214,22 m³ Fresh water: 123,99 m³ Water ballast: 3.979,10 m³ |
|
Anchor equipment |
3x Anchors weight each 4.050 kg Chain length: 522,50 m Diameter: 50 mm |
|
Cargo gear |
2x Cranes - 320 t SWL 1x Crane - 200 t SWL Combinable upto 640 t SWL |
|
ISM & commercial manager |
SAL Ship Management UG (haftungsbeschränkt) & Co. KGSAL Fleetholding I UG (haftungsbeschränkt) & Co. KG Brooktorkai 20 20457 Hamburg Federal Republic of Germany |
|
Registered owner |
SAL Fleetholding I UG (haftungsbeschränkt) & Co. KG Brooktorkai 20 20457 Hamburg Federal Republic of Germany |
|
Latest data adjustment |
17 Mai 2023 |
