Antwerpen 11 August 2015 |
 |
| Westerschelde 10/08/15 |
|
Name |
HHL NILE |
|
Previous names |
2009 - 10.2011 Beluga Faculty |
|
Type |
Multi-purpose dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo and grab fitted |
|
IMO-number |
9443669 |
|
Call sign |
ZDJL9 |
|
Flag |
Gibraltar |
|
Port of registry |
Gibraltar |
|
GT |
9.611 t Suez: 7.749 t |
|
DWT |
12.744 t |
|
NT |
4.260 t Panama: 8.427 t |
|
Number of 20ft containers |
On deck: 331 Under deck: 334 Total: 665 |
|
Reefer plug |
25 |
|
Length |
139,12 m overall 130,00 m between perpendiculars |
|
Breadth |
21,34 m extreme 21,01 m moulded |
|
Draught |
8,00 m |
|
Air draft |
39,40 m |
|
Depth |
11,00 m moulded |
|
Speed |
Max.: 15,0 knots Eco: 14,0 knots |
|
Built |
2009 |
|
Keel laid |
30.08.2007 |
|
Launch date |
11.03.2008 |
|
Date of completion |
21.08.2009 |
|
Builder |
CSC Jiangdong Shipyard |
|
Yard number |
JD12000-13 |
|
Hull material |
Steel |
|
Main engine |
1x MaK 6M43C - 6 cylinder diesel engine 5.400 kW |
|
Propellers |
1x Controllable pitch propeller |
|
Rudder |
Balanced flap type |
|
Boilers |
1x Thermal oil heater, exhaust heated 1x Thermal oil heater, oil fired |
|
Shaft generator |
1x 750 kW |
|
Generators |
3x MAN D2840 LE 301 diesel generatorsets each 395 kW |
|
Emergency generator |
1x MAN D2866E diesel generatorset 99 kW |
|
Bow thruster |
1x 500 kW |
|
Number of holds |
3x Double skinned, boxshaped / narrow stepwise in container dimensions |
|
Cargo hold capacity |
Hold 1: abt. 2.701 m³ / 95.350 ft³ Hold 2: abt. 8.362 m³ / 295.301 ft³ Hold 3: abt. 4.890 m³ / 172.689 ft³ Total: 15.952 m³ / 563.340 ft³ |
|
Hatch covers |
3 Hold 1: 19,30 m (18,75 m opening) x 15,42 m (15,00 m opening) Hold 2: 42,33 m (42,00 m opening) x 17,98 m (17,50 m opening) Hold 3: 26,00 m (25,50 m opening) x 17,98 m (17,50 m opening) |
|
Type hatch covers |
Hydraulic folding type |
|
Hatch cover area |
1.462 m² |
|
Tweendeck |
Hold 1: 18,75 m x 15,01 m Hold 2: 42,00 m x 17,50 m Hold 3: 25,50 m x 17,50 m |
|
Type tweendeck |
Moveable, Pontoons; can be used as vertical bulkheads in holds |
|
Lower hold |
Hold 1: 18,75 m x 15,01 m Hold 2: 42,00 m x 17,50 m Hold 3: 25,50 m x 17,50 m |
|
Heights |
Tanktop - Hatchcover: Hold 1: 10,53 m Hold 2: 11,18 m Hold 3: 10,77 m Tanktop - Tweendeck (bottom edge) Hold 1: 5,43 m Hold 2: 3,25 m / 6,00 m/ 7,45 m adjustable Hold 3: 5,59 m Tweendeck (top edge) hatchcover: Hold 1: 4,50 m Hold 2: 2,93 m / 4,38 m/ 7,13 m adjustable Hold 3: 4,38 m |
|
Max. permitted loads |
Tank top 16,0 t/m² Hatch covers 1,75 t/m² Tween deck: 4,0 t/m² |
|
Mechanical ventilation |
Hold 1: 6 fold Hold 2+3: 12 air change per hour |
|
Tank capacities |
Ballast: 5.003,9 m³ Freshwater: 128 m³ HFO: 948 m³ MGO: 150 m³ |
|
Anchor equipment |
Length: 545,42 m Diameter: 52 mm |
|
Cargo gear |
2x NMF electric hydraulic cranes - SWL 180 t each Combinable up to 360 t Outreach: 13 m / 180 t 16 m / 150 t 19 m / 120 t 24 m / 95 t 33 m / 70 t |
|
Manager |
Hansa Heavy Lift GmbH |
|
Previous managers |
2009 - 2011 Beluga Shipping GmbH |
|
Operator |
Hansa Heavy lift GmbH |
|
Owner |
Hansa Heavy Lift UG (haftungsbeschränkt) & Co. KG MS "HHL NILE" |
|
Registered owner |
B.V. Firmanten Amstelgracht 1042 AA Amsterdam |
|
Previous register owner |
Hansa Heavy Lift UG (haftungsbeschränkt) & Co. KG MS "HHL NILE" |
|
Renamed |
09.2016 Heemskerkgracht, Amsterdam - The Netherlands - Call sign: PBOQ |
|
Latest data adjustment |
20 January 2017 |
