Westerschelde 19 August 2017 |
 |
 |
 |
||
| Westerschelde 27/12/15 | Westerschelde 27/12/15 | Westerschelde 12/08/19 | ||
|
Name |
SCHELDEDIJK |
|
Type |
Multi-purpose dry cargo ship - Strengthened for heavy cargo - singledecker |
|
IMO-number |
9514925 |
|
Call sign |
PBMR |
|
Flag |
The Netherlands |
|
Port of registry |
Groningen |
|
GT |
2.984 t |
|
DWT |
Summer: 4.891 t |
|
NT |
1.598 t |
|
Light ship |
1.540 t |
|
Number of 20ft containers |
On deck: 38 |
|
Length |
89,95 m overall 84,94 m between perpendiculars |
|
Breadth |
14,40 m extreme |
|
Draught |
Summer: 6,22 m Winter: 6,09 m |
|
Air draft |
22,50 m keel to mast end 19,00 m mast down |
|
Depth |
7,85 m moulded |
|
Speed |
11,5 knots |
|
Built |
2010 |
|
Keel laid |
29/04/2008 |
|
Launch date |
26/04/2009 |
|
Date of completion |
15/02/2010 |
|
Builder |
Chowgule & Company Pvt. Ltd. Shipbuilding Division Loutulim Near Borim Bridge Loutulim Road Loutulim, 403718 Republic of India |
|
Yard number |
189 |
|
Hull material |
Shipbuilding steel (standard) Higher tensile steel |
|
Hull type |
Double bottom |
|
Movable bulkheads |
2x In 8 positions |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M25 - 4 stroke single acting 6 cylinder 255 x 400 mm combustion engine 1.980 kW / 2.840 bhp at 750 rpm Year of manufacture: 2006 Manufacturer: Caterpillar Motoren Guangdong Co. Ltd. (CMG), Foshan City - China |
|
Propellers |
1x Controllable pitch propeller - aft at 158 rpm |
|
Electric installations |
1x Plant 400 V - 210 kVA 1x Plant 400 V - 390 kVA 1x Plant 400 V - 210 kVA |
|
Shaft generator |
1x 390 kVA |
|
Generators |
1x Sisu 634 DSBIG diesel generatorset 210 kVA |
|
Emergency & harbour gen. |
1x Sisu 634 DSBIG diesel generatorset 210 kVA |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar |
|
Bow thruster |
1x 250 kW, forward |
|
Number of holds |
1 62,25 x 11,70 x 8,12 m |
|
Cargo hold capacity |
202.291 ft³ |
|
Number of hatches |
1 62,25 x 11,70 |
|
Pontoon hatch covers |
10 |
|
Max. permitted loads |
Tanktop: 15,0 t/m² Hatch covers: 1,6 t/m² |
|
Anchor equipment |
3x Anchors weight each 2.100 kg Length: 440,00 m Diameter: 36 mm |
|
Lifting equipment |
1x Gantry crane for pontoons |
|
Cargo gear |
Gearless |
|
Manager |
Navigia Shipmanagement B.V. Johan van Zwedenlaan 1 9744 DX Groningen The Netherlands |
|
Owner |
Beheermaatschappij Scheldedijk B.V. Groningen The Netherlands |
|
Registered owner |
Scheldedijk II B.V., Rhoon - The Netherlands Care of Navigia Shipmanagement BV Eenrumermaar 2 9735 AD Groningen The Netherlands |
|
Latest data adjustment |
235 August 2024 |
