Westerschelde 11 May 2017 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 30/04/19 | Antwerpen 26/05/16 | Antwerpen 26/05/16 | Westerschelde 13/04/20 | Westerschelde 12/03/17 | Westerschelde 12/03/17 | |||||
|
Name |
SCHELDEBANK |
|
Type |
Multi-purpose dry cargo ship - Heavycargo - Container ship with single box-shaped hold |
|
IMO-number |
9439474 |
|
Call sign |
PBJM |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
GT |
2.999 t |
|
DWT |
Summer: 4.539 t |
|
NT |
1.643 t |
|
Number of 20ft containers |
146 |
|
Length |
89,78 m overall 84,97 m between perpendiculars |
|
Breadth |
14,00 m moulded |
|
Draught |
Max.: 5,95 m |
|
Air draft |
25,90 m |
|
Freeboard |
1.561 mm |
|
Depth |
7,50 m moulded |
|
Speed |
Service: 13,0 knots |
|
Built |
2007 |
|
Keel laid |
21/02/2007 |
|
Launch date |
19/07/2007 |
|
Date of completion |
13/09/2007 |
|
Builder |
Ferus Smit Leer GmbH Leer Germany |
|
Yard number |
382 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Watertight compartments |
6 |
|
Movable bulkheads |
2 Equipped with movable hold separations / grain bulkheads in various positions |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M25 - 4 stroke single acting 8 cylinder 255 x 400 mm combustion engine 2.640 kW / 3.587 hp at 750 rpm Built: 19/04/2007 Builder: Caterpillar Motoren GmbH & Co. KG, Kiel - Germany |
|
Gearbox |
1x Flender GUCP-670 - Reduction: 3.74:1 |
|
Propellers |
1x Screw propeller controllable pitch - aft at 200 rpm Diameter: 3.200 mm - 4 blades |
|
Shaft generator |
1x 425 kVA / 340 kW |
|
Generators |
1x Scania DI-9 60M main diesel generatorset 235 kVA - 188 kW - 296 hp |
|
Emergency generator |
1x Scania DI-9 60M main diesel generatorset 235 kVA - 188 kW - 296 hp |
|
Bow thruster |
1x Jastram 275 kW |
|
Number of holds |
1x Box shaped 59,00 x 11,50/5,25 x 9,07 m |
|
Total capacity of holds |
Grain/ Bale: 5.676 m³ / 215.000 ft³ |
|
Number of hatches |
1 59,00 x 11,50 m |
|
Hatch type |
Pontoon hatch covers |
|
Hold ventilation |
8 changes/hour - Equipped with dehumidification system |
|
Max. permitted loads |
Tanktop: 15,0 t/m² Hatch cover: 1,6 t/m² |
|
Tank capacities |
Fresh water: 45 m³ Water ballast: 1.825 m³ Fuel: 422 m³ Lubricating oil: 20 m³ Dirty oil: 4,5 m³ Bilge water: 13 m³ Sludge: 11 m³ |
|
Cargo gear |
1x Handling of all pontoon hatch panels by gantry crane on coaming rails |
|
Accommodation |
7x All cabins air-conditioned |
|
Manager |
Wagenborg Shipping B.V. Marktstraat 10 9934 CKLDelfzijl The Netherlands |
|
Registered owner |
Bankship IV B.V. Handelskade West 28 A 9934 AA Delfzijl The Netherlands |
|
Latest data adjustment |
02 January 2023 |
