Westerschelde 20 February 2016 |
 |
| Westerschelde 20/02/16 |
|
Name |
SAGA FUJI |
|
Type |
General cargo ship- Open hatch - Single deck |
|
IMO-number |
9609457 |
|
Call sign |
VRMS3 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
GT |
37.499 t |
|
DWT |
Summer: 55.956 t |
|
NT |
15.805 t |
|
Number of 20ft containers |
On deck: 618 In holds: 1.376 |
|
Length |
199,90 m overall 194,02 m between perpendiculars |
|
Breadth |
32,26 m extreme |
|
Draught |
13,32 m |
|
Depth |
19,50 m |
|
Built |
2013 |
|
Keel laid |
15.12.2010 |
|
Launch date |
10.10.2013 |
|
Date of completion |
25.11.2013 |
|
Builder |
Oshima Shipbuilding Co., Ltd. |
|
Yard number |
10661 |
|
Hull material |
Steel |
|
Main engine |
1x Wärtsilä 6RT-flex50-D Builder: Wärtsilä Switzerland Ltd. |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary boiler, composite type OVS2-200/120-2W Builder: Osaka Mfg. |
|
Generators |
3x Hyundai 7H21/32 diesel generatorsets Builder: Hyundai Heavy Industries Co., Ltd. |
|
Emergency generator |
1x Cummins 6CTA8.3-D(M) diesel generatorset |
|
Number of holds |
10 Hold 1: 3.902 m³ / 137.797 ft³ Hold 2: 5.922 m³ / 209.151 ft³ Hold 3: 7.148 m³ / 252.439 ft³ Hold 4: 7.148 m³ / 252.439 ft³ Hold 5: 7.148 m³ / 252.439 ft³ Hold 6: 7.148 m³ / 252.439 ft³ Hold 7: 7.148 m³ / 252.439 ft³ Hold 8: 7.148 m³ / 252.439 ft³ Hold 9: 6;508 m³ / 229.841 ft³ Hold 10: 5.235 m³ / 184.900 ft³ Total: 64.458 m³ / 2.276.323 ft³ |
|
Tank capacities |
Ballast: 20.843 m³ |
|
Anchor equipment |
Length: 660,00 m Diameter: 78 mm |
|
Cargo gear |
2x Travelling Gantry cranes with weather protection - SWL 42 t each |
|
Manager |
Anglo-Eastern Ship Management Limited |
|
Operator |
Saga Welco AS Tenvikveien 373-375 |
|
Registered owner |
Pudding Shipholding S.A. |
|
Latest data adjustment |
06 March 2016 |
