Westerschelde 28 February 2016 |
|
Name |
SANTA HELENA 1 |
|
Previous names |
2012 - 2013 Santa Helena I |
|
Type |
Multi-purpose dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo Singledecker |
|
IMO-number |
9617325 |
|
Call sign |
5BNF3 |
|
Flag |
Cyprus |
|
Port of registry |
Limassol |
|
GT |
2.589 t |
|
DWT |
Summer: 3.785 t Winter: 3.660 t |
|
NT |
1.386 t |
|
Number of 20ft containers |
On deck: 36 |
|
Length |
89,92 m overall 83,96 m between perpendiculars |
|
Breadth |
12,90 m extreme 12,80 m moulded |
|
Draught |
5,55 m |
|
Air draft |
15,85 m |
|
Depth |
7,10 m moulded |
|
Speed |
11,0 knots |
|
Built |
2012 |
|
Keel laid |
19.12.2008 |
|
Launch date |
10.12.2011 |
|
Date of completion |
19.03.2012 |
|
Builder |
Slovenske Lodenice Komarno a.s. |
|
Yard number |
3803 |
|
Hull material |
Steel |
|
Movable bulkheads |
Moveable grain bulkheads with ten stowage positions |
|
Main engine |
1x Mak 8M20C - 8 cylinder diesel engine 1.520 kW Builder: Caterpillar motoren, Kiel - Germany |
|
Propellers |
1x Schottel controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired (Hot water heater) |
|
Generators |
1x Volvo Penta D9MG HE/KC main generatorsets each 239 kW |
|
Emergency generator |
1x Volvo Penta D7A T diesel generatorset 122 kW |
|
Compressed air receivers |
2x Starting air compressors |
|
Bow thruster |
1x Fixed pitch propeller type STT110LK - Output 185 kW at 790 rpm |
|
Number of holds |
1 57,85 x 10,2 0x 8,15 m |
|
Cargo capacity |
Boxshaped cargo hold fitted with three(03) bulk heads Hold (grain) with grain bulk heads 4.750 m³ / 167.667 ft³ Hold (bale) with grain bulk heads 4.636 m³ / 167.173 ft³ |
|
Max. permitted loads |
Tanktop: 15,0 t/m² Hatch: 1,56 t/m² |
|
Tank capacities |
Ballast: 1457,00 m³ HFO: 193,50 m³ MGO: 91,10 m³ Potable water: 52,00 m³ Lubrication oil: 13,90 m³ |
|
Anchor equipment |
Length: 476,50 m Diameter: 36 mm |
|
Accommodation |
For captain and crew of a total 9 persons with heating, ventilation and air-conditioning |
|
Manager |
Hermann Lohmann Bereederungen GmbH & Co. KG |
|
Owner |
Hermann Lohmann Bereederungen GmbH & Co. KG |
|
Renamed |
09/2013 Wilson Livorno Cyprus, Limassol - Call sign: 5BNF3 |
|
Latest data adjustment |
28 March 2016 |
