Name |
ERIEBORG |
Type |
Multi-purpose dry cargo ship - containership - heavycargo |
IMO-number |
9463437 |
Call sign |
PBVT |
Flag |
The Netherlands |
Port of registry |
Delfzijl |
GT |
7.196 t |
DWT |
11.197 t |
NT |
3.607 t |
Number of 20ft containers |
432 |
Length |
137,84 m overall 130,89 m between perpendiculars |
Breadth |
15,87 m |
Draught |
7,98 m |
Air draft |
30,63 m |
Depth |
11,00 m moulded |
Speed |
13,7 knots |
Built |
2009 |
Keel laid |
30/06/2008 |
Launch date |
17/09/2009 |
Date of completion |
27/11/2009 |
Builder |
Royal Niestern Sander BV Delfzijl The Netherlands |
Yard number |
839 |
Hull material |
Steel |
Watertight compartments |
5 |
Moveable bulkheads |
2 |
Continuous decks |
1 |
Main engine |
1x Wärtsilä - 4 stroke single acting 9 cylinder 320 x 400 mm combustion engine 4.500 kW / 6.114 hp at 750 rpm Built: 05/08/2009 Builder: Wärtsilä Finland Oy, Vaasa - Finland |
Propellers |
1x Screw propeller controllable pitch - aft at 151 rpm |
Boilers |
1x CHR 59,00 m² - 10,0 bar 1x CHO 26,20 m² - 10,0 bar |
Shaft generator |
1x 956 kVA - 765 kW |
Generators |
2x Main diesel generatorsets each 330 kVA - 264 kW - 380 hp |
Emergency generator |
1x Diesel generatorset 155 kVA - 124 kW - 177 hp |
Bow thruster |
1x 700 kW |
Number of holds |
2 Hold 1: 41,44 x 13,20 x 11,23 m Hold 2: 54,76 x 13,20 x 11,23 m |
Total capacity of holds |
13.644 m³ / 481.837 ft³ |
Number of hatches |
2 Hatch 1: 41,44 x 13,20 m Hatch 2: 54,76 x 13,20 m |
Hatch cover type |
Coops and Nieborg Pontoon Hatch cover system |
Tank capacities |
Fuel oil: 953,5 m³ |
ISM & commercial manager |
Wagenborg Shipping Marktstraat 10 9934 CK Delfzijl The Netherlands |
Registered owner |
Scheepvaartonderneming Erieborg BV Care of Wagenborg Shipping BV Marktstraat 10 9934 CK Delfzijl The Netherlands |
Latest data adjustment |
23 February 2023 |
