Name |
VICTORIADIEP |
|
Previous names |
06/2019 Victoriadiep |
|
Type |
Multi-purpose cargo ship - Tweendecker - Geared - strengthened for heavy cargoes - container cargoes in all holds and on all hatch covers |
|
IMO-number |
9351153 |
|
Call sign |
PHMM |
|
Flag |
The Netherlands |
|
Port of registry |
Groningen |
|
GT |
5.057 t |
|
DWT |
Summer: 7.450 t |
|
NT |
2.681 t |
|
Light weight |
2.681 t |
|
Number of 20ft containers |
On hatch: 201 In hold: 174 Total: 375 |
|
Number of 40ft containers |
On hatch: 59 + 19 TEU In hold: 84 Total: 143 - 19 TEU |
|
Container capacity 14t |
235 |
|
Length |
119,98 m overall 113,65 m between perpendiculars |
|
Breadth |
15,20 m moulded |
|
Draught |
Summer: 7,45 m |
|
Depth |
8,45 m to main deck |
|
Speed |
Max: 15,0 knots Service: 13,0 knots |
|
Built |
2007 |
|
Date of completion |
17/12/2007 |
|
Builder casco |
Zaliv Shipyards Kerch Ukraine |
|
Builder completion |
Bodewes Scheepswerven B.V. Hoogezand The Netherlands |
|
Yard number |
658 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M32 - 4 stroke single acting 8 cylinder 320 x 480 mm combustion engine 3.840 kW / 5.221 hp at 600 rpm Manufacturer: M.A.K. Caterpillar, Kiel - Germany |
|
Propellers |
1 |
|
Generators |
3x Scania DI1262-M09 P main diesel generatorsets each 265 kW |
|
Emergency generator |
1x Diesel generatorset 76 kW |
|
Bow thruster |
1x 300 kW |
|
Number of holds |
2 |
|
Hold capacity |
Hold 1: .4.306 m³ / 152.060 ft³ Hold 2: 5.288 m³ / 186.737 ft³ Total: 9.594 m³ / 338.797 ft³ |
|
Hold ventilation |
10 Air changes per hour |
|
Number of hatches |
2 Hatch 1: 27,22 x 12,65 m Hatch 2: 41,46 x 12,65 m |
|
Hatch type |
Pontoon type |
|
Max. permitted loads |
Tanktop: 25,0 t/m² Tweendeck: 3,5 t/m² Hatchcover: 1,75 t/m² |
|
Tank capacities 98% |
HFO: 561 m³ MGO: 80 m³ Fresh water: 50 m³ Water ballast: 3.313 m³ |
|
Cargo gear |
2x Cranes - SWL 60,0 t each Max. outreach: 25,00 m |
|
Crew complement |
12 |
|
Manager |
Feederlines B.V. Eenrumermaar 2 9735 AD Groningen The Netherlands |
|
Operator |
MTL |
|
Owner |
Sormano Victoria B.V. Groningen The Netherlands |
|
Previous names & owners |
08/2007 - 12/2007 Victoriadiep - Beheermaatschappij Victoriadiep B.V., Groningen - The Netherlands 12/2007 - 01/2011 OSC Victoriadiep - Beheermaatschappij Victoriadiep B.V., Groningen - The Netherlands 01/2011 - 07/2016 Victoriadiep - Beheermaatschappij Victoriadiep B.V., Groningen - The Netherlands |
|
Renamed |
06/2019 Sonreiras Spain, Santa Cruz de Tenerife - Call sign: EAZF Manager & owner: Naviera de Galicia S.A. (NAVIGASA), La Coruña - Spain 12/2022 Portugal, Madeira - Call sign: CQWM 01/2023 Joe Antigua & Barbuda, St. John's - call sign: V2HT6 Ownber & manager: Jens U. Waller, Drochtersen - Germany |
|
Latest data adjustment |
06 September 2023 |
