Westerschelde 26 June 2020 |
 |
 |
 |
||
| Westerschelde 09/09/16 | Westerschelde 25/04/16 | Westerschelde 25/04/16 | ||
|
Name |
VEENDIJK |
|
Type |
Multi-purpose dry cargo ship - Strengthened for heavy cargo - Box single decker |
|
IMO-number |
9346718 |
|
Call sign |
PBQQ |
|
Flag |
The Netherlands |
|
Port of registry |
Groningen |
|
GT |
2.984 t |
|
DWT |
Summer: 4.891 t |
|
DWCC |
Summer: 4.600 t Winter: 4.500 t |
|
NT |
1.598 t |
|
Number of 20ft containers |
38 on deck |
|
Length |
89,95 m overall 84,94 m between perpendiculars |
|
Breadth |
14,40 m extreme |
|
Draught |
6,22 m |
|
Air draft |
22,50 m keel/mast 19,00 m keel/mast down |
|
Depth |
7,85 m moulded |
|
Speed |
11,5 knots |
|
Built |
2009 |
|
Keel laid |
14/12/2007 |
|
Launch date |
01/11/2007 |
|
Date of completion |
17/06/2009 |
|
Builder |
Chowgule & Company Pvt. Ltd. Shipbuilding Mormugoa India |
|
Yard number |
C0178 |
|
Hull material |
Steel |
|
Movable bulkheads |
2x Grain bulkheads in 8 positions |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M25 - 4 stroke single acting 6 cylinder 255 x 400 combustion engine 1.980 kW at 750 rpm Manufacturer: M.A.K. Caterpillar, Kiel - Germany |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
Auxiliary boiler, oil/gas fired |
|
Generators |
1x Sisu 645 DSBIG main diesel generatorset |
|
Emergency & harbour gen. |
1x Sisu 645 DSBIG main diesel generatorset |
|
Bow thruster |
1x 250 kW |
|
Number of holds |
1 62,30 x 11,70 x 8,10 m Full box: 50,28 x 11,70 x 8,10 m |
|
Cargo hold capacity |
Grain: 5.818 m³ / 205.471 ft³ |
|
Number of hatches |
10 62,25 x 11,70 m |
|
Max. permitted loads |
Tanktop: 15,0 t/m² Hatch covers: 1,6 t/m² |
|
Tank capacities |
Water ballast: 1.821,87 m³ |
|
Anchor equipment |
Length: 385,00 m Diameter: 36 mm |
|
Lifting equipment |
1x Gantry crane for pontoons |
|
Cargo gear |
Gearless |
|
Crew |
8 |
|
Manager |
Navigia Shipmanagement B.V. Bornholmstraat 82 9723 AZ Groningen The Netherlands |
|
Registered owner |
C.V. Veendijk II C.V. Scheepvaartonderneming Groningen The Netherlands |
|
Previous names & owners |
06/2009 - 09/2014 Veendijk - B.V. Beheermaatschappij Veendijk, Groningen - The Netherlands |
|
Latest data adjustment |
23 June 2023 |
