Westerschelde 16 April 2016 |
 |
 |
 |
 |
|||
| Antwerpen 16/02/18 | Westerschelde 02/06/20 | Westerschelde 02/06/20 | Westerschelde 31/07/15 | |||
|
Name |
MARIETJE DEBORAH |
|
Type |
General cargo ship - heavycargo |
|
IMO-number |
9481594 |
|
Call sign |
PBWB |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
GT |
5.418 t |
|
DWT |
Summer: 8.334 t |
|
DWCC |
Summer: 7.850 t |
|
NT |
2.627 t |
|
Number of 20ft containers |
305 |
|
Length |
126,13 m overall 121,93 m between perpendiculars |
|
Breadth |
15,20 m moulded |
|
Draught |
Summer: 6,98 m Winter: 6,84 m |
|
Air draft |
25,00 m in ballast |
|
Freeboard |
2.536 mm |
|
Depth |
9,50 m moulded |
|
Speed |
13,0 knots |
|
Built |
2011 |
|
Launch date |
14/04/2011 |
|
Date of completion |
15/07/2011 |
|
Builder |
Scheepswerf & Machinefabriek Barkmeijer Stroobos B.V. Stroobos The Netherlands |
|
Yard number |
321 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x B&W-MAN 9L27/38 - 4 stroke single acting 9 cylinder 270 x 380 mm combustion engine 2.999 kW / 4.075 bhp at 800 rpm |
|
Propellers |
1x Screw propeller controllable pitch - aft at 152 rpm |
|
Boilers |
1x CHO Konutherm 16,10 m² - 10,0 bar 1x CHR Konutherm 47,00 m² - 10,0 bar |
|
Shaft generator |
1x 585 kVA - 468 kW |
|
Generators |
2x Main diesel generatorsets each 300 kVA - 240 kW |
|
Bow thruster |
1x 400 kW |
|
Number of cargo holds |
2 Hold 1: 20,71 x 12,80 x 9,38 m Hold 2: 68,63 x 12,80 x 9,38 m |
|
Total capacity of holds |
9.772 m³ / 330.771 ft³ |
|
Number of hatches |
2 Hatch 1: 20,71 x 12,80 m Hatch 2: 68,63 x 12,80 m |
|
Hatch type |
Coops & Nieborg pontoon hatches |
|
Tank capacities |
HFO: 500 m³ MGO: 85 m³ Water ballast capacity: 3.640 m³ Fresh water: 50 m³ |
|
ISM manager |
Danser van Gent M.D. II C.V. Delfzijl The Netherlands |
|
Commercial manager |
Wagenborg Shipping B.V. Marktstraat 10 9934 CK Delfzijl The Netherlands |
|
Registered owner |
H.J. Danser (Sr), Mevr. M.A.D. Danser & W.J. Schuur Care of Wagenborg Shipping BV Marktstraat 10 9934 CK Delfzijl The Netherlands |
|
Latest data adjustment |
23 February 2023 |
