| Westerschelde 07 April 2014 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 07/04/14 | Antwerpen 16/04/13 | Antwerpen 16/04/13 | Westerschelde 22/05/14 | Westerschelde 22/05/14 | Antwerpen 29/01/20 |
|
Name |
MARIETJE MARSILLA |
|
Type |
Multi-purpose dry cargo carrier single deck - Heavy cargo |
|
IMO-number |
9458248 |
|
Call sign |
PCIE |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
GT |
5.418 t |
|
DWT |
Summer: 8.334 t |
|
DWCC |
Summer: 7.850 t |
|
NT |
2.627 t |
|
Number of 20ft containers |
303 |
|
Length |
126,13 m overall 121,93 m between perpendiculars |
|
Breadth |
15,20 m overall |
|
Draught |
Summer: 6,98 m Winter: 6,84 m |
|
Air draft |
25,00 m in ballast |
|
Freeboard |
2.536 mm |
|
Depth |
9,50 m moulded |
|
Speed |
14,0 knots |
|
Built |
2010 |
|
Launch date |
25/06/2010 |
|
Date of completion |
04/11/2010 |
|
Builder |
Scheepswerf & Machinefabriek Barkmeijer Stroobos B.V. Hellingstraat 10 9872 PT Stroobos The Netherlands |
|
Yard number |
320 |
|
Hull material |
Steel |
|
Number of decks |
1 |
|
Main engine |
1x MAN-B&W 9L27/38 - 4 stroke single acting 9 cylinder 270 x 380 mm combustion engine 2.999 kW / 4.075 hp at 800 rpm Builder: MAN Diesel AS |
|
Propellers |
1x Screw propeller controllable pitch - aft at 152 rpm |
|
Boilers |
1x CHO Konutherm 16,10 m² - 10,0 bar 1x CHR Konutherm 47,00 m² - 10,0 bar |
|
Generators |
2x Diesel generatorsets each 300 kVA - 240 kW 2x Diesel generatorsets each 585 kVA - 468 kW |
|
Bow thruster |
400 kW |
|
Number of holds |
2x Fully box and double skinned Hold 1: 20,71 x 12,80 x 9,38 m Hold 2: 68,63 x 12,80 x 9,38 m |
|
Total capacity of holds |
Bale & grain: 9.772 m³ / 330.771 ft³ |
|
Hold ventilation |
9x Air-changes per hour basis empty holds. Both holds fitted with dehumidifier system |
|
Number of hatches |
2 Hatch 1: 20,71 x 12,80 m Hatch 2: 68,63 x 12,80 m |
|
Tween decks |
Vessel is equipped with 6 tween decks in hold 2 |
|
Tank capacities |
HFO: 274,14 m³ MGO: 220,3 m³ Water ballast: 3.691,5 m³ Fresh water: 53,09 m³ |
|
Manager |
Wagenborg Shipping B.V. Delfzijl The Netherlands |
|
Registered owner |
Danser Van Gent M.A. C.V. Collatorlaan 10 9934 PR Delfzijl The Netherlands |
|
Last update |
24 April 2020 |
