Westerschelde 14 September 2016 |
 |
 |
 |
 |
|||
| Westerschelde 13/02/19 | Antwerpen 27/01/17 | Antwerpen 27/01/17 | Antwerpen 16/02/18 | |||
|
Name |
NUNAVIK |
|
Type |
Icebreaking bulk carrier - Handysize |
|
IMO-number |
9673850 |
|
Call sign |
V7CK9 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
GT |
22.622 t |
|
DWT |
31.754 t |
|
NT |
8.841 t |
|
Length |
188,80 m overall 178,00 m between perpendiculars |
|
Breadth |
26,60 m extreme |
|
Draught |
11,75 m |
|
Depth |
15,70 m |
|
Speed |
13,0 knots laden |
|
Built |
2014 |
|
Keel laid |
19/07/2013 |
|
Launch date |
29/09/2013 |
|
Date of completion |
30/01/2014 |
|
Builder |
Japan Marine United Corporation, Tsu Shipyard Japan |
|
Yard number |
204 |
|
Hull material |
Steel |
|
Main engine |
1x MAN-B&W 7S70ME-C - 2 stroke 7 cylinder 700 x 2.800 mm combustion engine 22.072 kW / 30.006 hp |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler, composite - Vertical composite boiler 1x Auxiliary boiler, oil/gas fired - Vertical oil fired boiler Builder: Osaka Boiler MFG. Co., Ltd. |
|
Generators |
3x MAN 6L23/30H main diesel generatorsets each 780 kW |
|
Emergency generator |
1x Scania D9 diesel generatorset 181 kW Builder: Scania CV AB, Industrial & Marine Engines |
|
Number of holds |
5 Hold 1: 18,00 x 9,60 / 22,50 m Hold 2: 20,40 x 22,50 / 22,50 m Hold 3: 24,00 x 22,50 / 22,50 m Hold 4: 18,00 x 22,50 / 22,50 m Hold 5: 18,60 x 22,50/18,80 m |
|
Cargo hold capacity |
Grain Hold 1: 5.505 m³ Hold 2: 6.403 m³ Hold 3: 7.454 m³ Hold 4: 5.740 m³ Hold 5: 5.119 m³ Total: 30.221 m³ |
|
Number of hatches |
5 Hatch 1: 13,60 x 15,80 m Hatch 2: 13,80 x 15,80 m Hatch 3: 19,20 x 15,80 m Hatch 4: 13,80 x 15,80 m Hatch 5: 13,80 x 15,80 m |
|
Hatch cover type |
Folding hydraulic |
|
Tanktop strength |
Hold 1: 27.8 t/m² Hold 2: 27,0 t/m² Hold 3: 29,2 t/m² Hold 4: 28,1 t/m² Hold 5: 28,7 t/m² |
|
Tank capacities |
Ballast: 25.909 m³ IFO: 2.020 m³ MDO: 97 m³ |
|
Anchor equipment |
Length: 605,00 m Diameter: 66 mm |
|
Cargo gear |
2x Electro Hydraulic cranes - SWL 30,0 t each 1x Electro Hydraulic cranes - SWL 50,0 t |
|
Crew |
20 |
|
Commercial manager |
FEDNAV - Federal Commerce & Navigation Co. Ltd. Bureau 3500, 1000, rue de la Gauchetiere O Montreal QC H3B 4W5 Canada |
|
ISM manager |
Anglo-Eastern Ship Management Ltd. Hong Kong China |
|
Owner |
Fednav Group 1000 de La Gauchetière Street West, Suite 3500 Montreal, Quebec H3B 4W5 Canada |
|
Previous owners |
Federal Hudson Ltd., Majuro - Marshall islands Care of Fednav Ltd. Bureau 3500, 1000, rue de la Gauchetiere O Montreal QC H3B 4W5 Canada |
|
Sister ships |
Umiak I |
|
Latest data adjustment |
23 February 2024 |
