Westerschelde 19 March 2016 |
 |
 |
|
| Westerschelde 19/03/16 | Spijkenisse 15/06/16 |
|
Name |
DAIWAN BRAVE |
|
Type |
Bulk / Lumber carrier - Handysize |
|
IMO-number |
9672210 |
|
Call sign |
3FKG2 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
21.514 t registered |
|
DWT |
Summer: 34.358 t |
|
NT |
11.203 t registered |
|
Length |
179,96 m overall |
|
Breadth |
30,00 m moulded |
|
Draught |
Summer: 9,82 m |
|
Moulded L x B x D |
174,00 x 30,00 x 14,05 m |
|
Registered L x B x D |
174,54 x 30,00 x 14,05 m |
|
Freeboard |
Summer: 4.276 mm |
|
Depth |
14,05 m moulded |
|
Speed |
Service: 13,8 knots laden Max.: 15,8 knots |
|
Built |
2014 |
|
Keel laid |
28.09.2013 |
|
Launch date |
05.02.2014 |
|
Date of completion |
08.04.2014 |
|
Builder |
Namura Shipbuilding Co Ltd. |
|
Yard number |
372 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Kobe Diesel-Mitsubishi 6UEC45LSE - 2 stroke 6 cylinder 450 x 1.930 mm diesel engine 6.260 kW / 8.511 hp at 110,0 rpm Manufacturer: Kobe Diesel Co., Ltd. |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 450 mm |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary vertical boiler - 6,9 bar Evaporation: 1,39 t/h Manufacturer: Osaka Boiler Mfg. Co., Ltd. |
|
Generators |
4x Generators - total 1.766 kVA |
|
Number of holds |
5 |
|
Cargo hold capacity |
Bale: 42.911,2 m³ Grain: 44.154,6 m³ |
|
Number of hatches |
5 |
|
Tank capacities |
Fuel oil: 1.441 m³ Fresh water: 221 m³ |
|
Cargo gear |
4x Electro-hydraulic cranes - SWL 30,0 t each |
|
Manager |
Wisdom Marine Lines SA |
|
Operator |
Wisdom Line |
|
Registered owner |
Katagalan Star S.A. Taiwan |
|
Latest data adjustment |
25 February 2017 |
