Antwerpen 06 April 2015 |
|
Name |
HC NADJA MARIA |
|
Previous names |
2000 - 11/2000 Beatrice 11/200 - 02/2013 Carola |
|
Type |
Multi-purpose geared dry cargo ship - Strengthened for heavy cargo - Equipped for carrying container Box-Hold MPP, single/tweendecker, geared, box |
|
IMO-number |
9214173 |
|
Call sign |
V2AV4 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
GT |
6.382 t |
|
DWT |
Abt. 9.000 t abt 7,45 m summer draft |
|
NT |
3.419 t |
|
Container capacity 14t |
In hold: 262 On deck: 300 Total: 562 |
|
Reefer plug |
60 |
|
Length |
129,42 m overall 123,08 m between perpendiculars |
|
Breadth |
15,85 m |
|
Draught |
Summer: 7,45 m |
|
Depth |
9,75 m |
|
Speed |
15,0 knots Economic: 13,0 knots |
|
Built |
2000 |
|
Builder casco |
Damen Shipyard Galati Romania |
|
Builder completion |
Damen Shipyard Hoogezand Hoogezand The Netherlands |
|
Hull material |
Steel |
|
Main engine |
1x MaK 9M32 - 9 cylinder combustion engine 4.320 kW at 600 rpm |
|
Propellers |
1x Controllable pitch propeller |
|
Bow thruster |
400 kW |
|
Number of holds |
Hold 1: 38,97 x 13,15 x 11,05 m Hold 2: 52,19 x 13,15 x 11,05 m All heights without tweendeck Moveable bulkheads/ boxshaped Partly fitted with 14 tweendecks |
|
Hold capacities |
Grain/Bale: 451.144 ft³ / 12.775 m³ without tweendecks: Hold 1 abt 184.873 ft³ / 5.235 m³ Hold 2 abt 266.271 ft³ / 7.540 m³ with tweendecks: Hold 1 abt 4.970,9 m³ Hold 2 abt 7.087,9 m³ |
|
Cargo hold ventilations |
Hold 1: 26.000 m³/h x 2 pcs Hold 2: 36.000 m³/h x 2 pcs |
|
Number of hatches |
Hatch 1: 38,97 x 13,15 m Hatch 2: 52,19 x 13,15 m |
|
Floor space |
Total of abt 2.615 m² of which: Weatherdeck : Hold 1: 510 m³ / Hold 2: 686 m² Tweendeck: Hold 1: 343 m³ / Hold 2: 609 m³ Tanktop: Hold 1: 466 m³ / Hold 2: 669 m² tweendeck panels can be placed in hold 1 or 2 or as bulkheads |
|
Deck strength |
Tanktop: 20 t/m² Tweendeck: 3,5 t/m² Weatherdeck: 1,75 t/m² |
|
Tank capacities |
Ballast: 3.661 m³ Fresh water: 76,2 m³ |
|
Cargo gear |
2x Liebherr cranes, starboard side mounted, each SWL 60 t lifting capacity at 16,00 m outreach Combinable up to 120 t Capacity/Outreach: 60 t/16,00 m - 40 t/26,00 m - 30 t/28,40 m |
|
Crew |
12 |
|
Manager |
Imm Shipping Management Ahrensburg Hamburger Straße 131 Germany |
|
Operator |
HC Chartering GmbH & Co. KG Hamburger Straße 131 22926 Ahrensburg Germany |
|
Owner |
IMM Shipping GmbH & Co KG |
|
Renamed |
06/2020 Knidos Republic of Panama, Panama City - Call sign: 3EYR8 |
|
Latest data adjustment |
26 July 2020 |
