Antwerpen 03 may 2016 |
|
Name |
PIONER |
|
Russian name |
ПИОНЕР |
|
Previous names |
1997 - 09.2001 Aukse 09.2001 - 01.2003 Torm Aukse 01.2003 - 06.2008 Aukse 06.2008 - 12.2013 Blue Spirit |
|
Type |
General cargo ship / Container ship |
|
IMO-number |
9113032 |
|
Call sign |
UBDK9 |
|
Flag |
Russia |
|
Port of registry |
Arkhangelsk |
|
GT |
3.893 t |
|
DWT |
Summer: 5.833 t |
|
NT |
2.533 t |
|
Displacement |
7.768 t |
|
Number of 20ft containers |
353 |
|
Container capacity 14t |
253 |
|
Reefer capacity |
50 |
|
Length |
102,83 m overall 97,20 m between perpendiculars |
|
Breadth |
15,94 m extreme 15,85 m moulded |
|
Draught |
6,54 m |
|
Depth |
8,10 m |
|
Speed |
13,5 knots |
|
Built |
1997 |
|
Date of completion |
01.03.1997 |
|
Builder |
Baltija Shipbuilding Yard |
|
Yard number |
302 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Bulkheads |
6 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN 8L32/40 - 4 stroke 8 cylinder 320 x 400 mm diesel engine 3.520 kW at 750 rpm Built: 1996 |
|
Propellers |
1x Controllable pitch propeller - aft at 240 rpm 4 blades |
|
Shaft generator |
1x 700 kVA - 560 kW |
|
Generators |
1x Main diesel generatorsets each 433 kVA - 346 kW - 530 hp |
|
Emergency generator |
1x Diesel generatorset 170 kVA - 136 kW - 224 hp |
|
Bow thruster |
375 kW |
|
Number of holds |
2x Box steel-floored Hold 1: 33,17 x 12,87 x 8,28 m |
|
Hold capacity |
Grain/Bale: 6.903 m³ / 6.876 m³ |
|
Number of hatches |
2 2x 32,70 x 13,35 m each |
|
Hatch type |
hydraulic folding steel hatch covers |
|
Tank capacities |
Fuel oil: 335.00 m³ |
|
Cargo gear |
2x Cranes port side - SWL 36,0 t each |
|
Owner |
Eco Shipping Ltd. Ul. Karla Marksa, d. 15, office 207 163000 Arkhangelsk |
|
Latest data adjustment |
19 May 2017 |
