Westerschelde 28 January 2017 |
 |
 |
|
| Westerschelde 28/01/17 | Westerschelde 28/01/17 |
|
Name |
COS ORCHID |
|
Type |
Bulk carrier |
|
IMO-number |
9308704 |
|
Call sign |
S6EA5 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
GT |
30.853 t registered |
|
DWT |
Summer: 55.539 t |
|
NT |
18.171 t registered |
|
Length |
189,90 m overall |
|
Breadth |
32,26 m moulded |
|
Draught |
Summer: 12,52 m |
|
Moulded L x B x D |
185,00 x 32,26 x 17,80 m |
|
Registered L x B x D |
185,00 x 32,26 x 17,80 m |
|
Freeboard |
Summer: 5.320 mm |
|
Depth |
17,80 m moulded |
|
Speed |
16,0 knots |
|
Built |
2004 |
|
Keel laid |
24.12.2004 |
|
Launch date |
12.12.2005 |
|
Date of completion |
23.02.2006 |
|
Builder |
Nantong COSCO KHI Ship Engineering Co., Ltd. |
|
Yard number |
039 |
|
Hull material |
Steel |
|
Main engine |
1x Hudong MAN B&W 6S50MC-C - 2 stroke single acting 6 cylinder 500 x 2.000 mm diesel engine 8.200 kW at 110 rpm Manufacturer: Hudong Heavy Machinery Co.,Ltd. Foundry Branch |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 490 mm |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary vertical boiler - 8,0 bar Evaporation: 3,35 t/h Manufacturer: Aalborg(Qingdao) Boiler Company Ltd. |
|
Generators |
4x Generators - 2.189 kW |
|
Hold capacity |
Bale: 66.966 m³ Grain: 69.452 m³ |
|
Tank capacities |
Fuel oil: 2.003 m³ Fresh water: 375 m³ |
|
Manager |
COSCO Corporation Singapore Limited |
|
Registered owner |
COSCO (Singapore) Pte Ltd. |
|
Latest data adjustment |
01 July 2017 |
