Antwerpen 25 May 2017 |
|
Name |
OCEAN MARVEL |
|
Previous names |
2009 - 2015 Mosor |
|
Type |
Bulk carrier |
|
IMO-number |
9191527 |
|
Call sign |
D5JZ6 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
2009 - 2015 Croatia, Split - call sign: 9AIS |
|
GT |
24.533 t |
|
DWT |
Summer: 42.584 t |
|
NT |
13.770 t |
|
Length |
187,63 m overall 178,94 m between perpendiculars |
|
Breadth |
30,80 m extreme |
|
Draught |
Summer: 10,98 m |
|
Depth |
15,45 m moulded |
|
Speed |
14,0 knots |
|
Built |
2001 |
|
Keel laid |
07.12.1999 |
|
Launch date |
27.10.2000 |
|
Date of completion |
12.07.2001 |
|
Builder |
Brodosplit brodogradilište d.o.o. Split Croatia |
|
Yard number |
409 |
|
Hull material |
Steel |
|
Main engine |
1x MAN B&W 5S50MC - 5 cylinder diesel engine output 7.150 kW at 127 rpm Builder: MAN Diesel & Turbo, Branch of MAN Diesel & Turbo SE - Germany |
|
Propellers |
1x Mono-block propeller |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated 1x Auxiliary boiler, oil/gas fired |
|
Generators |
3x Wärtsilä 4L20 main diesel generatorsets Builder: Wärtsilä Finland Oy |
|
Number of holds |
5 Hold 1: 24,00 x 15,40 x 29,30 m Hold 2: 28,80 x 29,30 x 30,80 m Hold 3: 28,80 x 30,80 x 30,80 m Hold 4: 28,80 x 30,80 x 30,80 m Hold 5: 28,80 x 30,80 x 28,70 m |
|
Cargo hold capacity |
Bale: 263,776 m³ / Grain: 276,780 m³ Bale: 368,636 m³ / Grain: 385,620 m³ Bale: 358,003 m³ / Grain: 371,176 m³ Bale: 368,724 m³ / Grain: 385,592 m³ Bale: 372,489 m³ / Grain: 386,022 m³ Total: Bale: 1.731,62 m³ / Grain: 1.805,49 m³ |
|
Number of hatches |
5 Hatch 1: 12,80 x 16,00 m Hatch 2: 19,20 x 16,00 m Hatch 3: 19,20 x 16,00 m Hatch 4: 19,20 x 16,00 m Hatch 5: 19,20 x 16,00 m |
|
Tank capacities |
Ballast: 15.850,5 m³ |
|
Anchor equipment |
Length: 275,00 m Diameter: 68 mm |
|
Cargo gear |
4 Electro - hydraulic cargo cranes: Max outreach: abt 26,00 m |
|
Manager |
Kaalbye Shipping International Ltd. |
|
Registered owner |
Kaalbye Shipping International Ltd. |
|
Latest data adjustment |
30 June 2017 |
