Westerschelde 14 December 2018 |
 |
 |
|
| Westerschelde 14/12/18 | Vlissingen 05/10/15 |
|
Name |
ANKIE |
|
Type |
Multi-purpose dry cargo carrier / Containership |
|
IMO-number |
9331359 |
|
Call sign |
PHKA |
|
Flag |
The Netherlands |
|
Port of registry |
Spijk |
|
GT |
2.528 t |
|
DWT |
Summer: 3.638 t |
|
DWCC |
Summer: 3.350 t |
|
NT |
1.053 t |
|
Number of 20ft containers |
157 |
|
Length |
89,99 m overall 84,95 m between perpendiculars |
|
Breadth |
12,50 m overall |
|
Draught |
Summer: 5,31 m Winter: 5,20 m |
|
Air draft |
22,75 m in ballast |
|
Depth |
8,00 m moulded |
|
Speed |
Service: 10,6 knots Max: 13,0 knots |
|
Built |
2007 |
|
Keel laid |
2006 |
|
Launch date |
18/11/2006 |
|
Date of completion |
24/04/2007 |
|
Builder casco |
Shipyard Leda d.o.o. Korcula Croatia |
|
Builder completion |
Scheepswerf Peters B.V. Kampen The Netherlands |
|
Yard number |
1207 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 9L20 - 4 stroke single acting 9 cylinder 200 x 280 mm combustion engine 1.800 kW / 2.447 hp at 1.000 rpm Manufacturer: Wärtsilä Diesel Oy, Turku - Finland |
|
Propellers |
1x Controllable pitch propeller |
|
Bow thruster |
1x 250 kW |
|
Number of holds |
1 60,00 x 10,30 x8,15 m |
|
Cargo hold capacity |
Grain/bale: 174.063 ft³ - 4.927 m³ |
|
Number of hatches |
1 60,00 x 10,30 m |
|
Hatch type |
Pontoon |
|
Tank capacities |
MGO: 285 m³ Water ballast: 1.466 m³ fresh water: 25 m³ |
|
Cargo gear |
Gearless |
|
Commercial manager |
Wagenborg Shipping BV Marktstraat 10 9934 CK DelfzijL The Netherlands |
|
ISM manager |
Scheepvaartbedrijf Van Dam Hoofdweg-Noord 34 9909 AD Spijk The Netherlands |
|
Registered owner |
C.V. Ankie Care of CV Scheepvaartonderneming van Dam (Scheepvaartbedrijf van Dam) Seendweg 6 9936 GA Farmsum The Netherlands |
|
Latest data adjustment |
04 February 2022 |
