Name |
MACAW ARROW |
|
Type |
General dry cargo single deck- Open hatch jib crane carrier - Fleximax III |
|
IMO-number |
9566617 |
|
Call sign |
LAJU8 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
Previous flags |
2014 - 12/2009 Bahamas, Nassau - Call sign: C6AT5 |
|
GT |
44.866 |
|
DWT |
Summer: 72.400 t |
|
NT |
22.321 |
|
Length |
209,99 m overall 206,02 m between perpendiculars |
|
Breadth |
36,00 m extreme |
|
Draught |
13,77 m |
|
Depth |
19,54 m |
|
Speed |
14,5 knots |
|
Built |
2014 |
|
Keel laid |
11/07/2013 |
|
Launch date |
13/11/2013 |
|
Date of completion |
10/01/2014 |
|
Builder |
Oshima Shipbuilding Co., Ltd. Nagasaki Japan |
|
Yard number |
10663 |
|
Hull material |
Steel |
|
Main engine |
1x Mitsui/MAN-B&W 5S60ME-C8.2 TII - 2 stroke 5 cylinder combustion engine 9.450 kW / 12.848 hp |
|
Propellers |
1x Nakashima fixed pitch propeller - 5 blades |
|
Boilers |
1x Auxiliary boiler, composite GCS-23ST Manufacturer: Alfa Laval |
|
Generators |
2x Hyundai 6H21/32 diesel generatorsets each 1.000 kW 1x Hyundai 5H21/32 diesel generatorset 835 kW Manufacturer: Hyundai Heavy Industries Co., Ltd. |
|
Emergency generator |
1x Deutz TCD914L06M diesel generatorset |
|
Bow thruster |
1.600 kW |
|
Number of cargo holds |
8 Hold 1: 15,81 x 15,50 x 20,50 m Hold 2-7: 19,50 x 30,60 x 20,50 m Hold 8: 17,70 x 20,60 x 19,00 m |
|
Cargo hold capacity |
Bale/Grain: 84.125 m³ |
|
Tank capacities |
Ballast: 26.829 m³ |
|
Anchor equipment |
Length: 687,50 m Diameter: 81 mm |
|
Cargo gear |
4x Cranes - SWL 45,0 t Grabs: 4x 15 m³ |
|
ISM & commercial manager |
Gearbulk Norway AS Ytrebygdsvegen 215 5258 Blomsterdalen Norway |
|
Operator |
Gearbulk |
|
Registered owner |
Gearbulk Shipowning Ltd. Ytrebygdsvegen 215 5258 Blomsterdalen Norway |
|
Latest data adjustment |
06 January 2025 |
