Westerschelde 22 March 2016 |
 |
| Westerschelde 19/06/20 |
|
Name |
VIKINGBANK |
|
Type |
General cargo ship - Heavycargo - Container ship |
|
IMO-number |
9604184 |
|
Call sign |
PCOR |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
GT |
7.367 t |
|
DWT |
Summer: 11.850 t |
|
DWCC |
Summer: 11.300 t |
|
NT |
3.688 t |
|
Number of 20ft containers |
475 |
|
Length |
142,65 m overall 139,43 m between perpendiculars |
|
Breadth |
15,87 m moulded |
|
Draught |
Ma.: 7,73 m |
|
Air draft |
30,60 m in ballast |
|
Freeboard |
3.071 mm |
|
Depth |
10,78 m moulded |
|
Speed |
14,0 knots |
|
Built |
2012 |
|
Keel laid |
26/05/2010 |
|
Launch date |
17/03/2012 |
|
Date of completion |
19/04/2012 |
|
Builder |
Scheepswerf Ferus Smit B.V Westerbroek The Netherlands |
|
Yard number |
406 |
|
Hull material |
Steel |
|
Movable bulkheads |
2x Movable bulkheads, that can be used as 4 tween-decks |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M32 - 4 stroke single acting 8 cylinder 320 x 480 mm combustion engine 4.000 kW / 5.435 bhp at 750 rpm Builder: Caterpillar Motoren GmbH & Co. KG , Kiel - Germany |
|
Propellers |
1x Screw propeller controllable- aft at 159 rpm 4 blades - diameter: 4,00 m |
|
Boilers |
1x CHO 12,70 m² - 7,5 bar |
|
Shaft generator |
1x 850 kVA - 680 kW |
|
Generators |
1x Diesel generatorset 131 kVA - 105 kW - 512 hp 2x Diesel generatorsets each 388 kVA - 310 kW - 512 hp |
|
Bow thruster |
1x 600 kW |
|
Number of holds |
2x Fully box Hold 1: 41,00 x 13,20 x 10,78 m Hold 2: 63,63 x 13,20 x 10,78 m |
|
Total capacity of holds |
Grain/Bale: 14.258 m³ / 503.821 ft³ |
|
Number of hatches |
2 Hatch 1: 41,00 x 13,20 m Hatch 2: 63,63 x 13,20 m |
|
Hatch type |
Coops & Nieborg pontoon hatches |
|
Max. permitted loads |
Tanktop: 15,0 t/m² Tweendeck: 3,5 t/m² Weatherdeck: 1,75 t/m² |
|
Tank capacities |
HFO: 530 m³ MGO: 39,8 m³ Water ballast: 5.300 m³ Fresh water: 53 m³ |
|
Manager |
Wagenborg Shipping B.V. Marktstraat 10 9934 CK Delfzijl The Netherlands |
|
ISM manager |
Pot Scheepvaart Delfzijl The Netherlands |
|
Registered owner |
C.V. Scheepvaartonderneming Vikingbank Delfzijl The Netherlands |
|
Latest data adjustment |
07 May 2021 |
