Name |
EASTERN VANQUISH |
|
Previous names |
08/2012 - 11/2015 Bijlberg |
|
Type |
Multi-purpose general cargo ship - Heavycargo - Container ship |
|
IMO-number |
9411836 |
|
Call sign |
2IXV6 |
|
Flag |
United Kingdom |
|
Port of registry |
London |
|
Previous flags |
08/2012 - 11/2015 The Netherlands, Werkendam - Call sign: PCPG |
|
GT |
2.281 t |
|
DWT |
3.577 t |
|
NT |
1.170 t |
|
Number of 20ft containers |
In hold: 56 On deck: 48 Total: 104 |
|
Length |
88,97 m overall 84,99 m between perpendiculars |
|
Breadth |
11,80 m moulded |
|
Draught |
Summer max: 5,40 m Winter max: 5,29 m |
|
Air draft |
At ballast: 17,90 m at 3,50 m draught |
|
Freeboard |
1.860 mm |
|
Depth |
6,95 m moulded |
|
Speed |
11,0 knots |
|
Built |
2012 |
|
Launch date |
24/11/2009 |
|
Date of completion |
02/08/2012 |
|
Builder casco |
NSC Marine Corporation (Nine Sun Group) Nantong China |
|
Builder completion |
Bijlsma Shipyard B.V. (Veka) Lemmer The Netherlands |
|
Yard number |
772 |
|
Hull material |
Steel |
|
Movable bulkheads |
2x Moveable bulkheads (7 positions) |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 8L80C - 4 stroke single acting 8 cylinder 200 x 280 mm combustion engine 1.440 kW / 2.037 hp at 1.000 rpm Builder: Wärtsilä Vaasa Finland Oy |
|
Propellers |
1x Screw propeller controllable pitch |
|
Shaft generator |
1x 390 kVA - 312 kW |
|
Generators |
1x Main diesel generatorset 175 kVA - 140 kW - 247 hp |
|
Emergency generator |
1x Diesel generatorset 81 kVA - 65 kW - 95 hp |
|
Bow thruster |
1x 285 kW |
|
Number of holds |
1 62,50 x 9,60 x 7,42 m |
|
Total capacity of holds |
155.300 ft³ / 4.400 m³ |
|
Number of hatches |
1 62,50 x 9,60 m |
|
Hatch type |
Pontoon (11 pcs) |
|
Max. Permitted loads |
Tanktop: 12,0 t/m² Hatchcover: 1,75 t/m² |
|
Tank capacities |
Bunker: 193 m³ Fresh water: 45 m³ Ballast water: 1.458 m³ |
|
Manager |
VMS Shipping B.V. Winschoten The Netherlands |
|
Commercial manager |
Longship BV |
|
Previous managers |
08/2012 - 12/2012 Q Shipping B.V., Barendrecht - The Netherlands 12/2012 - 07/2015 VMS Shipping B.V., Winschoten - The Netherlands 07/2015 - 11/2015 NedNor B.V., Groningen - The Netherlands |
|
Registered owner |
Eastern Shipping Ltd. London United Kingdom |
|
Previous names & owners |
08/2012 - 11/2015 Bijlberg - Bijlberg C.V., Werkendam - The Netherlands |
|
Latest data adjustment |
28 February 2018 |
