Westerschelde 06 July 2016 |
 |
|
| Westerschelde 31/07/16 | |
|
Name |
PAPAU |
|
Type |
Bulk carrier |
|
IMO-number |
9266906 |
|
Call sign |
ZGHA4 |
|
Flag |
Cayman Islands |
|
Port of registry |
George Town |
|
Previous flags |
2003 - 2011 Malta, Valletta - Call sign: 9HPI7 2011 - 2017 Liberia, Monrovia - Call sign: D5AD3 |
|
GRT |
19.796 t registered |
|
DWT |
Summer: 31.817 t |
|
NRT |
11.034 t registered |
|
Displacement |
39.449 t |
|
Length |
176,82 m overall |
|
Breadth |
29,40 m moulded |
|
Draught |
Summer: 9,56 m |
|
Moulded L x B x D |
168,00 x 29,40 x 13,50 m |
|
Registered L x B x D |
168,56 x 29,40 x 13,50 m |
|
Keel to mast end |
42,00 m |
|
Freeboard |
Summer: 3.979 mm Winter: 4.140 mm |
|
Depth |
13,50 m moulded |
|
Speed |
Service: 14,2 knots Max: 16,3 knots |
|
Built |
2003 |
|
Keel laid |
20/02/2003 |
|
Launch date |
13/05/2003 |
|
Date of completion |
17/07/2003 |
|
Builder |
The Hakodate Dock Co., Ltd. Tokyo Japan |
|
Yard number |
791 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Bulkheads |
7 |
|
Continuous decks |
1 |
|
Main engine |
1x Mitsubishi 6UEC52LA - 2 stroke single acting 6 cylinder 520 x 1.600 mm combustion engine 6.620 kW at 130,0 rpm Manufacturer: Akasaka Diesels Ltd. |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 430 mm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary vertical boiler - 7,0 bar Evaporation: 1,90 t/h Manufacturer: Tortoise Engineering Co., Ltd. |
|
Generators |
3x Generatorsets total 1.080 kVA |
|
Number of cargo hold |
5 |
|
Cargo hold capacity |
Bale: 39.680 m³ Grain: 40.960 m³ |
|
Number of hatches |
5 |
|
Tank capacities |
Fuel oil: 1.413 m³ Diesel oil: 90 m³ Fresh water: 161 m³ Ballast: 12.650 m³ |
|
Lifting equipment |
2x Cranes - SWL 0,5 t each 1x Crane - SWL 1,5 t |
|
Cargo gear |
4x Deck cranes - SWL 30 t each |
|
Commercial manager |
Johann M.K. Blumenthal GmbH & Co. KG Palmaille 120, 22767 Hamburg Germany |
|
ISM manager |
Blumenthal Asia Pte Ltd. 31-01A, Springleaf Tower, 3, Anson Road Singapore 079909 Republic of Singapore |
|
Registered owner |
Vocation Shipping Company Limited Care of Johann M K Blumenthal GmbH & Co KG Palmaille 118-120 22767 Hamburg Germany |
|
Latest data adjustment |
22 May 2023 |
