| Westerschelde 28 March 2019 |
 |
| Westerschelde 14/05/20 |
|
Name |
BRO DESIGNER |
|
Type |
Oil and chemical carrier |
|
IMO-number |
9313101 |
|
Call sign |
OZFP2 |
|
Flag |
Demnark |
|
Port of registry |
København |
|
Previous flags |
2006 - 2010 Sweden - Call sign: SHWU |
|
GT |
11.344 t |
|
DWT |
Summer: 14.846 t |
|
NT |
4.704 t |
|
Displacement |
20.578,9 t |
|
Length |
146,80 m overall 134,40 m between perpendiculars |
|
Breadth |
22,00 m moulded |
|
Draught |
Summer: 8,20 m |
|
Keel to mast end |
39,50 m |
|
Freeboard |
3.607 mm |
|
Depth |
11,80 m moulded |
|
Speed |
Max: 13,0 knots |
|
Built |
2006 |
|
Keel laid |
18/02/2005 |
|
Delivery date |
21/06/2006 |
|
Builder |
China Merchants Jinling Shipyard (Nanjing) Co., Ltd. No. 55 Yan Jiang Road, Nanjing, Jiangsu Nanjing China |
|
Yard number |
JLZ030508 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
2x MAN-B&W L27/38 - 7 cylinder 270 x 380 mm combustion engine each Mcr 2.280 kW at 800 rpm Total: 4.760 kW / 6.472 hp |
|
Propellers |
2 |
|
Boilers |
1x Composite boiler port Mission OC - 9,0 MPa 1x Composite boiler starboard Mission OC - 9,0 MPa |
|
Generators |
4x MAN-B&W 6L16/24 generatorsets each 570 kW |
|
Bow thruster |
1x 1.050 kW |
|
Number of tanks |
13 + 2 slop tanks |
|
Cargo tank capacity |
18.970,80 m³ |
|
Number of pumps |
13x Cargo pumps each 385 m³/h |
|
Tank capacities |
Diesel oil: 296,70 m³ Fresh water: 440,70 m³ Hydraulic oil: 19,00 m³ Ballast: 7.403,70 m³ Fuel oil: 748,30 m³ |
|
Commercial manager |
Moller-Maersk A/S Copenhagen Denmark |
|
ISM managers |
Maersk Tankers A/S Copenhagen Denmark |
|
Registered owner |
Brostrom AB Copenhagen Denmark |
|
Renamed |
12/03/2021 Nightcrawler Marshall Island, Majuro - Call sign: V7A4584 Owner: Uranus Partners Co., Ltd., Tokyo - Japan Operator: Bernhard Schulte Shipmanagement (Singapore) Pte Ltd. |
|
Latest data adjustment |
13 January 2022 |
