| Westerschelde 21 December 2019 |
 |
 |
 |
||
| Westerschelde 21/12/19 | Westerschelde 18/02/20 | Westerschelde 26/04/20 | ||
|
Name |
ENCELIA |
|
Previous names |
2003 - 2006 Apanemo 2006 - 2017 Silvaplana |
|
Type |
Crude oil/Product carrier |
|
IMO-number |
9240172 |
|
Call sign |
HZKA |
|
Flag |
Saudi Arabia |
|
Port of registry |
Jeddah |
|
Previous flags |
Greece - Call sign: SYLY 2017 - 2021 Dominica, Portsmouth - Call sign: J7DX4 |
|
GT |
62.216 t Suez: 65.901,16 t |
|
DWT |
109.250 t |
|
NT |
32.117 t Suez: 58.502,84 t |
|
Length |
249,90 m overall 239,00 m between perpendiculars |
|
Breadth |
43,99 m extreme |
|
Draught |
Summer: 14,26 m |
|
Keel to mast end |
49,87 m |
|
Air draft |
Summer deadweight: 37,58 m Normal ballast: 42,53 m Lightship: 47,37 m |
|
Freeboard |
Summer: 7.719 mm Winter: 7.996 mm |
|
Depth |
21,00 m moulded |
|
Speed |
15,2 knots |
|
Built |
2003 |
|
Keel laid |
22/04/2002 |
|
Date of completion |
10/01/2003 |
|
Builder |
Daewoo Shipbuilding & Marine Engineering Co., Ltd. South Korea |
|
Yard number |
5221 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x HDS/MAN-B&W 6S70MC-C MK7 - 2 stroke 6 cylinder combustion engine 14.340 kW at 89,0 rpm |
|
Propellers |
1x Fixed pitch propeller |
|
Generators |
3x Yanmar / 6N21(L)-EV main diesel generatorsets each 750 kW at 720 rpm |
|
Number of tanks |
12 + 2 slop tanks |
|
Cargo tank capacity 98% |
Liquid: 124.980,7 m³ |
|
Capacity of each natural segregation 98% |
Seg 1: 41.298,6 m³ (1wings, 4wings, slop p+s) Seg 2: 43.965,2 m³ (2wings, 5wings) Seg 3: 42.119,9 m³ (3wings, 6wings) |
|
Slop tank capacity 98% |
2.401,6 m³ |
|
Number of pumps |
3x Centrifugal cargo pumps each 3.000 m³/h 2x Centrifugal ballast pumps each 3.000 m³/h |
|
Manifolds |
Distance bridge front to centre of manifold: 81,54 m Bow to centre manifold: 125,56 m Stern to centre manifold 124,00 m Distance between cargo manifold centres: 2.500 mm Distance ships rail to manifold: 4.457 mm Distance manifold to ships side: 4.600 mm Top of rail to centre of manifold: 720 mm Distance main deck to centre of manifold: 2.100 mm Spill tank grating to centre of manifold: 900 mm |
|
Tank capacities |
Fuel oil: 2.887,9 m³ Diesel oil: 228,2 m³ Gas oil: 733,30 m³ |
|
Commerical manager |
Bihar International Co., Ltd. Al-Bakri Building, al-Maadi Street, corner of al-Andalus Street, ar-Ruwais District Jeddah, 21481 Saudi Arabia |
|
ISM manager |
Red Sea Marine Services LLC Office 405, Swiss Tower, Jumeirah Lake Towers Cluster Y3, Sheikh Zayed Road, Al Barsha 1 Dubai United Arab Emirates |
|
Registered owner |
Trans Mediterranean Shipping Care of Bihar International Co Ltd , Al-Bakri Building, al-Maadi Street, corner of al-Andalus Street, ar-Ruwais District Jeddah, 21481 Saudi Arabia |
|
Latest data adjustment |
01 March 2022 |
