| Westerschelde 10 May 2020 |
 |
| Westerschelde 10/05/20 |
|
Name |
DREGGEN |
|
Type |
Chemical tanker |
|
IMO-number |
9416070 |
|
Call sign |
LARQ8 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
Previous flags |
2008 - 2018 Republic of Panama, Panama City - Call sign: 3FSS3 2018 - 2022 Cayman Islands - George town - Call sign: ZGHP9 |
|
GT |
11.722 t Suez: 12.171,45 t |
|
DWT |
Summer: 19.993,78 t Winter: 19.395,97 t |
|
NT |
6.321 t Suez: 10.518,88 t Panama: 9.890 t |
|
Displacement |
Summer: 25.359,52 t Winter: 24.761,71 t |
|
Length |
144,09 m overall 136,46 m between perpendiculars |
|
Breadth |
24,23 m extreme |
|
Draught |
Summer: 9,63 m Winter: 9,43 m |
|
Keel to mast end |
37,65 m |
|
Air draft |
Summer deadweight: 28,02 m Normal ballast: 31,85 m Lightship: 35,34 m |
|
Freeboard |
Summer: 3.270 mm Winter: 3.470 mm |
|
Depth |
12,90 m moulded |
|
Speed |
14,0 knots - Economic: 11,50 knots Max: 17,0 knots |
|
Built |
2008 |
|
Date of completion |
12/11/2008 |
|
Builder |
Fukuoka Shipbuilding Co., Ltd. Fukuoka Japan |
|
Yard number |
F-1272 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
13 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 6S42MC (MARK 6) - 2 stroke 6 cylinder 420 x 1.764 mm combustion engine 6.150 kW / 8.356 hp at 136,0 rpm Build: 01/04/2008 Manufacturer: Hitachi Zosen Corporation Innoshima Works, Innoshimahabu - Japan |
|
Propellers |
1x Screw propeller solid aft at 136,0 rpm |
|
Generators |
3x Yanmar 6N18AL-SV Main diesel generatorsets each 700 kVA - 560 kW - 836 hp |
|
Emergency generator |
1x Diesel generatorset 60 kVA - 48 kW - 82 hp |
|
Bow thruster |
1x 860 bhp |
|
Number of tanks |
20 |
|
Cargo tank capacity 98% |
Tank 1p: 626,38 m³ Tank 1s: 639,537 m³ Tank 2p: 1.209,56 m³ Tank 2s: 1.223,61 m³ Tank 3p: 1.548,32 m³ Tank 3s: 1.550,42 m³ Tank 4p: 1.391,77 m³ Tank 4s: 1.406,11 m³ Tank 5p: 732,61 m³ Tank 5s: 745,40 m³ Tank 6p: 1.316,76 m³ Tank 6s: 1.317,79 m³ Tank 7p: 1.392,27 m³ Tank 7s: 1.404,16 m³ Tank 8p: 1.308,82 m³ Tank 8s: 1.309,47 m³ Tank 9p: 695,48 m³ Tank 9s: 708,19 m³ Tank 10p: 587,03 (slop P) m³ Tank 10s :600,28 (slop s) m³ Liquid: 20.526,73 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
Tank 10p: 587,03 (slop P) m³ Tank 10s :600,28 (slop s) m³ |
|
Number of pumps |
1x Horizontal centrifugal ballast pump 400 m³/h 12x Centrifugal cargo pumps each 300 m³/h 8x Centrifugal cargo pumps each 200 m³/h |
|
Manifolds |
Bow to centre manifold: 72,79 m Stern to centre manifold: 71,30 m Distance bridge front to centre of manifold: 43,00 m Distance between cargo manifold centers: 400 mm Distance ships rail to manifold: 5,500 mm Distance manifold to ships side: 5,700 mm Top of rail to centre of manifold: 1.165 mm Distance main deck to centre of manifold: 2.993 mm Spill tank grating to centre of manifold: 1.165 mm |
|
Tank capacities |
Fuel oil: 573,80 m³ Diesel oil: 478,10 m³ |
|
Lifting equipment |
1x Crane - SWL 5,0 t |
|
Commercial manager |
Hansa Tanker A/S Kalfarveien 57A 5022 Bergen |
|
ISM manager |
Diamond Ship Management Pte Ltd. #31-01, M Tower 460 Alexandra Road Singapore 119963 Republic of Singapore |
|
Registered owner |
Chem Tank Invest AS Kalfarveien 57a 5022 Bergen Norway |
|
Latest data adjustment |
08 July 2022 |
