| Westerschelde 12 Mrach 2020 |
|
Name |
STAR PLOEG |
|
Type |
Chemical tanker |
|
IMO-number |
9749790 |
|
Call sign |
ZGFI5 |
|
Flag |
Cayman Islands |
|
Port of registry |
George Town |
|
GRT |
12.082 t Suez: 12.393,09 t |
|
DWT |
Summer: 19.997,21 t Winter: 19.395,49 t |
|
NRT |
6.319 Suez: 10.627,74 t Panama: 10.160 t |
|
Displacement |
Summer: 25.643,47 t Winter: 25.041,75 t |
|
Length |
146,50 m overall |
|
Breadth |
24,00 m moulded |
|
Draught |
Summer: 9,77 m Winter: 9,57 m |
|
Keel to mast end |
38,57 m |
|
Moulded L x B x D |
138,00 x 24,00 x 13,10 m |
|
Registered L x B x D |
138,44 x 24,00 x 13,10 m |
|
Air draft |
Summer deadweight: 28,80 m Normal ballast: 32,93 m Lightship: 36,11 m |
|
Freeboard |
Summer: 3.364 mm Winter: 2.560 mm |
|
Depth |
13,10 m moulded |
|
Speed |
Max: 14,0 knots Eco: 12,0 knots |
|
Built |
2015 |
|
Keel laid |
25/07/2016 |
|
Launch date |
26/12/2015 |
|
Date of completion |
30/03/2016 |
|
Builder |
Fukuoka Shipbuilding Co., Ltd. Japan |
|
Yard number |
F-1309 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W 6S42MC7 - 2 stroke 6 cylinder 420 x 1.764 mm combustion engine 4.440 kW - 6.036 hp at 117,0 rpm Manufacturer: Makita Corporation |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 390 mm |
|
Propellers |
1 |
|
Boilers |
1x Vertical water tube boiler - 0,93 MPa Evaporation: 15;95 t/h Manufacturer: Tortoise Engineering Co., Ltd. |
|
Generators |
3x Yanmar 6EY18ALW main diesel generatorsets each 560 kW |
|
Bow thruster |
1x 871,5 bhp |
|
Number of tanks |
20 |
|
Cargo tank capacity 98% |
Liquid: 20.680,42 m³ |
|
Capacity natural segregation with double valve |
1P: 606,591 m³ 1S: 622,997 m³ 2P: 1.156,069 m³ 2S: 1.171,662 m³ 3P: 1.528,703 m³ 3S: 1.528,703 m³ 4P: 1.399,418 m³ 4S: 1.415,011 m³ 5P: 737,214 m³ 5S: 752,410 m³ 6P: 1.399,694 m³ 6S: 1.415,277 m³ 7P: 1.399,890m³ 7S: 1.415,480 m³ 8P: 1.369,023 m³ 8S: 1.384,616 m³ 9P: 681,285 m³ 9S: 696,377 m³ 10P: 573,518 m³ (Slop tank) 10S: 588,634 m³ (Slop tank) |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
1.162,15 m³ |
|
Number of pumps |
2x Horizontal centrifugal ballast pumps each 250 m³/h 12x Centrifugal pumps each 300 m³/h 8x Centrifugal pumps each 200 m³/h |
|
Manifolds |
Distance bridge front to centre of manifold: 43,40 m Bow to centre manifold: 75,60 m Stern to centre manifold: 70,90 m Distance between cargo manifold centres: 400 mm Distance ships rail to manifold: 4.400 mm Distance manifold to ships side: 4.600 mm Top of rail to centre of manifold: 690 mm Distance main deck to centre of manifold: 2.331 mm Spill tank grating to centre of manifold: 642 mm |
|
Tank capacities |
HFO: 759,747 m³ Diesel oil: 233,53 m³ Fresh water: 232,72 m³ |
|
Lifting equipment |
1x Crane - SWL 10,0 t |
|
Commercial manager |
Hansa Tankers AS Bergen Norway |
|
ISM manager |
Diamond Ship Management Pte. Ltd. Republic of Singapore |
|
Registered owner |
Inventor Chemical Tanekrs AS Bergen Norway |
|
Renamed |
04/2023 Floyen Norway, Bergen - Call sign: LATN8 Reg. owner: Chem Tank Shipping X AS, Bergen - Norway Commercial manager: Chem Tank Shipping X AS, Bergen - Norway ISM manager: Diamond Ship Management Pte. Ltd., - Republic of Singapore |
|
Latest data adjustment |
07 August 2023 |
