Westerschelde 15 August 2018 |
 |
| Westerschelde 15/08/18 |
|
Name |
STAR KESTREL |
|
Previous names |
2008 - 04/2010 Gan Sabree 04/2010 - 01/2013 Nord Sound |
|
Type |
Tanker for oil and chemicals |
|
IMO-number |
9321940 |
|
Call sign |
3EVC2 |
|
Flag |
Republic of panama |
|
Port of registry |
Panama City |
|
Previous flags |
2008 - 2010 Liberia 2010 - 2013 Republic of Singapore |
|
GT |
30.228 t Suez: 31.209,92 t |
|
DWT |
Summer: 49.842 t |
|
NT |
13.648 t Suez: 26.369,02 t Panama: 30.029 t |
|
Displacement |
Summer: 60.033 t Winter: 59.996 t |
|
Length |
183,00 m overall 173,90 m between perpendiculars |
|
Breadth |
32,23 m extreme |
|
Draught |
Summer: 12,88 m Winter: 12,87 |
|
Keel to masthead |
46,03 m |
|
Air draft |
33,18 m at summer deadweight 38,61 m normal ballast 43,49 m lightship |
|
Freeboard |
Summer: 6.230 mm Winter: 6.237 mm |
|
Depth |
19,17 m |
|
Speed |
Max: 14,9 knots 13,0 knots ballast - 12 knots economical 13,0 knots laden - 11,5 knots economical |
|
Built |
2008 |
|
Keel laid |
13/09/2007 |
|
Launch date |
18/11/2007 |
|
Date of completion |
11/01/2008 |
|
Builder |
STX Offshore & Shipbuilding Co., Ltd. Jinhae |
|
Yard number |
1216 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x 6S50MC-C - 6 cylinder combustion engine 9.480 kW |
|
Propellers |
1x Mono-block propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired 1x Auxiliary boiler, composite |
|
Generators |
3x 6L23/30H main diesel generatorsets each 795 kW |
|
Number of cargo tanks |
2 |
|
Total tank capacity 98% |
52.138,27 m³ |
|
Capacity (98%) of each natural segregation |
Seg#1: 6.155,14 m³ (1P & 1 S) |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
1.408,35 m³ |
|
Pumps |
2x Ballast centrifugal Framo Pump with Vac Stripper each 750 m³/h 12x Centrifugal - Framo Deepwell cargo pumps each 600 m³/h 2x Centrifugal - Framo Deepwell cargo pumps each 300 m³/h 1x Centrifugal - Framo Deepwell cargo pump each 150 m³/h 1x Screw type Framo pump 20 m³/h |
|
Manifolds |
Distance bridge front to centre of manifold: 56,26 m Bow to centre manifold: 92,10 m Stern to centre manifold: 90,90 m Distance between cargo manifold centres: 2.000 mm Distance ships rail to manifold: 4.600 mm Distance manifold to ships side: 4.600 mm Top of rail to centre of manifold: 740 mm Distance main deck to centre of manifold: 2.100 mm Spill tank grating to centre of manifold: 900 mm |
|
Tank capacities |
Fuel oil: 1.576,50 m³ Gas oil: 236,40 m³ Ballast: 24.170,4 m³ |
|
Anchor equipment |
Length: 625,50 m Diameter: 73 mm |
|
Lifting equipment |
1x Crane - SWL 10,0 t |
|
Manager |
Interorient Marine Services (Germany) GmbH & Co. KG |
|
Technical operator |
Interorient Marine Services (Germany) GmbH & Co. KG |
|
Commerical operator |
Koch Shipping Pte Ltd. |
|
Registered owner |
APSF Owning Company 4 Limited |
|
Latest data adjustment |
29 November 2018 |
