| Westerschelde 01 March 2019 |
 |
 |
|
| Westerschelde 01/03/19 | Westerschelde 01/03/19 | |
|
Name |
HIGH LEADER |
|
Type |
Chemical/Oil products tanker |
|
IMO-number |
9814155 |
|
Call sign |
3EVN9 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GRT |
29.447 t |
|
DWT |
49.929 t |
|
NRT |
13.750 t |
|
Length |
182,50 m overall |
|
Breadth |
32,20 m moulded |
|
Draught |
Summer: 13,12 m |
|
Moulded L x B x D |
175,00 x 32,20 x 19,05 m |
|
Registered L x B x D |
175,02 x 32,20 x 19,05 m |
|
Freeboard |
Summer: 5.965 mm |
|
Depth |
19,05 m moulded |
|
Speed |
14,5 knots |
|
Built |
2018 |
|
Keel laid |
21/12/2015 |
|
Launch date |
22/12/2017 |
|
Date of completion |
29/06/2018 |
|
Builder |
Japan Marine United Corporation, Maizuru Shipyard Japan |
|
Yard number |
5143 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x 2 stroke single acting 6 cylinder 500 x 2.214 mm combustion engine 8.310 kW / 11.298 hp at 114,0 rpm Manufacturer: Mitsui Engineering & Shipbuilding Co., Ltd. Tamano Works, Japan |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 530 mm |
|
Propellers |
11x Fixed pitch propeller |
|
Boilers |
1x Auxiliary vertical boiler - 0,88 MPa Evaporation: 17,55 t/h Manufacturer: Osaka Boiler Mfg. Co., Ltd. |
|
Generators |
4x Generatorsets total 3.64 kVA |
|
Cargo tank capacity |
Liquid: 55.031 m³ |
|
Tank capacities |
Fuel oil: 2.492,0 m³ Fresh water: 472,8 m³ |
|
Commercial manager |
D'Amico Tankers Dac The Anchorage, 17-19, Sir John Rogerson's Quay Dublin 2 Ireland |
|
ISM manager |
Synergy Navis Marine Private Limited 3rd Floor, ONYX, North Main Road, Koregaon Park, Pune Maharashtra, 411001 India |
|
Registered owner |
Grace Hawk Shipping S.A. Care of Eiko Kisen Co Ltd. 712-1, Kinoura, Hakata-cho, Imabari-shi Ehime-ken, 794-2305 Japan |
|
Latest data adjustment |
01 September 2023 |
