| Westerschelde 12 March 2018 |
 |
|
| Westerschelde 12/03/18 | |
|
Name |
BOW ATLANTIC |
|
Previous names |
1995 - 04/2007 Brage Atlantic |
|
Type |
Chemical/Oil products tanker |
|
IMO-number |
9102928 |
|
Call sign |
PU6253 |
|
Flag |
Brazil |
|
Port of registry |
Sao Paulo |
|
Previous flags |
1995 - 04/2007 Norway, Bergen - Call sign: LAVB4 04/2007 - 07/2022 Republic of Singapore, Singapore City- Call sign: S6AT6 |
|
GT |
10.460 m |
|
DWT |
17.460 m |
|
NT |
5.540 t |
|
Light displacement |
5.803 t |
|
Length |
142,44 m overall 132,40 m Between perpendiculars |
|
Breadth |
22,83 m extreme |
|
Draught |
Summer: 9,72 m |
|
Keel to mast end |
37,50 m |
|
Depth |
13,00 m moulded |
|
Speed |
13,6 m |
|
Build |
1995 |
|
Keel laid |
06/06/1994 |
|
Launch date |
15/02/1995 |
|
Date of completion |
07/07/1995 |
|
Builder |
Kvarener Kleven Ulsteinvik AS Ulsteinvik Norway |
|
Yard number |
262 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M552C - 4 stroke 8 cylinder 450 x 500 mm combustion engine 6.000 kW / 8.158 hp at 500 rpm |
|
Propellers |
1x Controllable pitch propeller |
|
Bow thruster |
1x 736 kW |
|
Number of tanks |
24 |
|
Cargo tank capacity |
Liquid: 19.188 m³ |
|
Number of pumps |
10x Cargo pumps each 300 m³/h 14x Cargo pumps each 200 m³/h |
|
Commercial manager |
Odfjell Asia II Pte Ltd. 27-08/9, OUE Downtown 2 6, Shenton Way Singapore 068809 Republic of Singapore |
|
ISM manager |
Flumar Transportes De Quimicos 18 andar, Avenida Paulista 460, Bela Vista Sao Paulo SP, 01310-904 Brazil |
|
Registered owner |
Odfjell Asia II Pte Ltd. 27-08/9, OUE Downtown 2 6, Shenton Way Singapore 068809 Republic of Singapore |
|
Previous names & owners |
1995 - 04/2007 Brage Atlantic - Bras Shipping B.V. |
|
Renamed |
Graceful Star Republic of Panama, Panama City - Call sign: 3E6660 Registered owner: Graceful Star Shipping Co Ltd. |
|
Latest data adjustment |
16 September 2024 |
