Name |
BOTHNIA |
|
Previous names |
2002 Build as: OW Bothnia 09/2002 - 03/2013 Bothnia 03/2013 - 03/2015 Orabothnia |
|
Type |
Chemical & oil tanker |
|
IMO-number |
9485356 |
|
Call sign |
CQAN6 |
|
Flag |
Portugal |
|
Port of registry |
Madeira |
|
Previous flag |
2012 - 2012 Denmark - Call sign: OWEC2 2013 - 2013 Cyprus, Limassol- Call sign: 5BTZ3 2013 - 2021 Gibraltar - Call sign: ZDNK2 |
|
GT |
6.382 t |
|
DWT |
Summer: 8.985,04 t |
|
NT |
2.660 t |
|
Length |
118,16 m overall 110.98 m between perpendiculars |
|
Breadth |
18,63 m extreme 18,49 m moulded |
|
Draught |
Summer: 7,90 m 5,10 m ballast |
|
Height from keel to mast |
37,60 m |
|
Air draft |
34,92 m ballast 29,70 m loaded condition |
|
Depth |
10,00 m moulded |
|
Speed |
Max: 14,5 knots Service: 12,5 knots |
|
Built |
2013 |
|
Keel laid |
07/09/2009 |
|
Launch date |
05/05/2011 |
|
Date of completion |
11/01/2013 |
|
Builder |
Zhenjiang Sopo Shiprepair & Building Co Ltd - Zhenjiang JS Yard |
|
Yard number |
SP0701 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Number of decks |
1 |
|
Main engine |
2x MaK 6M25 - 4 stroke single acting 6 cylinder 255 x 400 mm combustion engine each 1.980 kW / 2.692 hp at 750 rpm Total 3.960 kW / 5.284 hp Builder: Caterpillar Motoren GmbH & Co. KG - Germany |
|
Propellers |
2x Controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired 1x Auxiliary boiler, composite |
|
Shaft generators |
2x 900 kW |
|
Generators |
2x Hyundai/Himsen 5H17/28 - 4 stroke 5 cylinder 170 x 280 diesel engine each Mcr 600 kW connected with generators each 550 kW |
|
Emergency generator |
1x 6CTA8.3-D(M) Cummins diesel generatorset |
|
Bow thruster |
1x Tunnel thruster 441 kW / 600 bhp, forward |
|
Number of cargo tanks |
10 + 2 slop tanks |
|
Cargo tank capacity 98% |
9.360,2 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
143,9 m³ |
|
Number of segregations |
5 double valves + Slops |
|
Pumps |
2x Cargo pumps each 500 m³/h 3x Cargo pumps each 400 m³ /h 2x Cargo pumps each 80 m³/h 2x Ballast pumps each 250 m³/h |
|
Number of manifolds |
6 |
|
Manifolds |
Distance from bow to centre manifold: 57,70 m Distance from stern to centre manifold: 60,40 m Distance between manifolds: 1,50 m Distance from ship side to manifold: 4,00 m Distance from deck / tray to manifold: 3,60 m |
|
Tank capacities |
Ballast: 3.914 m³ |
|
Anchor equipment |
Length: 525,90 m Diameter: 48 mm |
|
Lifting equipment |
3x Cranes - SWL 2,0 t each |
|
Crew size |
12 |
|
ISM & commercial manager |
South End Tanker Management B.V. Aventurijn 218 3316 LB Dordrecht The Netherlands |
|
Registered owner |
Ciresa Shipping B.V. Care of South End Tanker Management BV Aventurijn 218 3316 LB Dordrecht The Netherlands |
|
Latest data adjustment |
18 December 2022 |
