Name |
HARINGVLIET |
|
Type |
Oil tanker |
|
ENI-number |
02334123 |
|
Call sign |
PB9023 |
|
Flag |
The Netherlands |
|
Port of registry |
Geertruidenberg |
|
Tonnage |
3.508 t |
|
Length |
110,00 m |
|
Breadth |
13,50 m |
|
Draught |
3,65 m |
|
Air draft |
7,85 m |
|
Depth |
6,00 m |
|
Built |
2010 |
|
Builder casco |
Barkmet Shipyard A.S. |
|
Builder completion |
De Waal Machinefabriek B.V |
|
Hull type |
Double hull coated |
|
Main engine |
1x ABC 6 MDZC - 1.324 kW / 1800 hp at 1.000 rpm Builder: Anglo Belgian Corporation N.V. |
|
Reduction |
1x Reintjes reduction type WGF 763 - 3,007:1 |
|
Propeller |
1x 5-Blades diameter 1. 700 mm Cunial Tiprake propeller with nozzle 1.710 mm |
|
Generators |
Caterpillar TYPE C32 diesel engine coupled with Stamford generator type HCM534`F2 - 725 kVA (60 Hz.) for driving bow thruster and pumps |
|
Bow thruster |
1x Caterpillar - Verhaar Omega - 571 hp/ 426 kW at 1.780 rpm |
|
Cargo capacity 100% |
4.115 m³ |
|
Number of pumps |
11x MarFlex electrically driven Deepwell loading pumps type MDPD-80 each 100 m³/h 1x MarFlex electrically driven Deepwell ballast pump type MBDPC-200 - 400 m³/h 1x Bornemann twin-screw pomp type EPS50 - 65 m³/h at 4,0 bar driving by electric motor 15 kW |
|
Owner |
Interstream Barging B.V. The Netherlands |
|
Latest data adjustment |
08 May 2015 |
