| Antwerpen 14 August 2009 |
|
Name |
MARIA SOLTIN |
|
Previous names |
1972 - 1981 Odabo 1981 - 1991 Unicorn Odabo 1991 - 1999 Maria Theresa 1999 Maria Soltin |
|
Type |
Oil and chemical tanker |
|
IMO-number |
7203699 |
|
Call sign |
OWOA6 |
|
Flag |
Denmark |
|
Port of registry |
Copenhagen |
|
GT |
807 t |
|
DWT |
1.193 t |
|
NT |
247 t |
|
Length |
65,81 m overall 60,40 m between perpendiculars |
|
Breadth |
9,65 m moulded |
|
Draught |
Summer: 3,92 m Ballast: 3,68 m |
|
Height from keel to mast |
24,00 m |
|
Air draft |
In ballast: 17,00 m Loaded condition: 16,00 m |
|
Depth |
4,22 m moulded |
|
Speed |
11,3 knots |
|
Built |
1972 Rebuilt: 1991 |
|
Launch date |
15.01.1972 |
|
Date of completion |
03.1972 |
|
Builder |
Krogerwerft |
|
Yard number |
1382 |
|
Main engine |
1x B&W Alpha 10V23HU diesel - 920 kW / 1.550 bhp |
|
Propellers |
1 |
|
Generators |
2x MWN RHS 518A 1x MWN RHS 518S |
|
Bow thruster |
1x 330 bhp |
|
Number of cargo tanks |
8 |
|
Number of segregations |
4 Double valves |
|
Cargo tank capacity |
933 m³ (98%) |
|
Slop tank capacity |
126 m³ (98%) |
|
Ballast tank capacity |
556 m³ |
|
TPC |
10,0 t |
|
Size of manifolds |
4'' |
|
Manifolds |
Distance from bow to centre manifold: 28,00 m Distance from stern to centre manifold: 37,00 m Distance between manifolds: 41 cm Distance from ship side to manifold: 3,67 m Distance from deck / tray to manifold: 53 cm |
|
Cargo pumps |
4x Deepwell pumps each 100 m³/h 1x Centrifugal pump 180 m³/h |
|
Ballast pumps |
1x 300 m³/h |
|
Coating |
ST/ST Centre tanks - 664 m³ Epoxy wing tanks - 269 m³ |
|
Manager |
Soltin Shipmanagement AS |
|
Operator |
Uni-Chartering A/S |
|
Owner |
Soltin Marine A/S |
