| Westerschelde 05 August 2019 |
 |
 |
 |
 |
|||
| Antwerpen 12/07/10 | Antwerpen 12/07/10 | Vlissingen 14/05/19 | Vlissingen 28/08/17 | |||
|
Name |
MARIA THERESA |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9228590 |
|
Call sign |
OWOX2 |
|
Flag |
Denmark |
|
Port of registry |
Struer |
|
GT |
2.659 t |
|
DWT |
Summer: 4.473 t Winter: 4.213 t |
|
NT |
1.301 t |
|
Length |
92,27 m overall 86,34 m between perpendiculars |
|
Breadth |
13,60 m |
|
Draught |
Summer: 6,15 m |
|
Air draft |
27,00 m |
|
Freeboard |
1.510 mm |
|
Depth |
7,65 m |
|
Speed |
11,50 knots |
|
Built |
2002 |
|
Keel laid |
15/05/2000 |
|
Launch date |
25/08/2001 |
|
Date of completion |
25/03/2002 |
|
Builder |
RMK Marine Shipyard (RMK Marine Gemi Yapim San. ve Deniz Tasimaciligi Isl. A.S) Tuzla, Istanbul Turkey |
|
Yard number |
47 |
|
Hull material |
Steel |
|
Hull type |
Double sides, double bottom |
|
Main engine |
1x MaK 6M25 - 4 stroke 6 cylinder 250 x 400 mm combustion engine - 1.850 kW / 2.514 hp at 750 rpm Builder: Caterpillar Motoren GmbH & Co. KG, Kiel - Germany |
|
Electrical propulsion gen. |
1x 280 kW 400 Volt |
|
Propelling system |
1x Screw propeller controllable pitch - aft at 184 rpm |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated (Economizer) 1x Auxiliary boiler, oil/gas fired |
|
Electrical installation |
Power voltage: 400 V Lighting voltage: 230 V Frequency: 50 Hz |
|
Shaft generator |
350 kVA |
|
Generators |
2x MAN D2842 LE301 main diesel generatorset each 625 kVA - 500 kW - 723 hp |
|
Emergency generators |
1x Diesel generatorset 100 kVA - 80 kW - 129 hp |
|
Bow thruster |
240 kW |
|
Number of tanks |
14 12x Marine line coated cargo tanks 4.560 m³ (98%) 2x 6 wing tanks, symmetric loading at sea only |
|
Separate deck tanks |
1x 20 m³ 1x 25 m³ |
|
Total capacity of tanks |
4.745,20 m³ |
|
Tank capacities |
Fuel oil: 143 m³ in tanks protected from sea by double hull Diesel oil: 35 t in tanks protected from sea by double hull Water ballast: 1.675 m³ |
|
Segregation |
6 grades by separate line and pumps |
|
Cargo handling |
12x Pres-Vac deepwell pumps 1.200 m³/h |
|
Loading rate |
750 m³/h maximum depending on circumstances |
|
Discharging rate |
750 m³/h maximum depending on circumstances |
|
Heating capacity |
Maintain about 85°C. with outside temperature 0°C |
|
Tank cleaning system |
Each tank is fitted with 2 fixed machines which generate a total 22 m³/h. Deck tanks available for effective and fuel saving cleaning with smallest possible amount of water. |
|
Cargo lines |
6x 4 inch stainless pipe |
|
Vapour system |
2x 6 inch separate common lines systems |
|
Manifolds |
Manifold to deck: 2,00 m Manifold to platform: 1,50 m Manifold to stern: 45,00 m Manifold to bow: 48,00 m Manifold to rail: 2,00 m |
|
Crane |
1x Hydraulic driven - SWL 1.000 kg at 15,00 m |
|
Tank capacities |
Ballast: 1.675,43 m³ |
|
Anchor equipment |
Length: 467,50 m Diameter: 36 mm |
|
ISM& commercial manager |
Christiania Shipping A/S Amerika Plads 38 2100 København Denmark |
|
Registered Owner |
Christiania Shipping A/S Amerika Plads 38 2100 København Denmark |
|
Previous owner |
Herning Shipping A.S., 7400 Herning - Denmark |
|
Renamed |
2022 Sana United Arab Emirates, Dubai - Call sign: A6E2147 Owner & manager: Halifax Marine Shipchandlers Co. LLC |
|
Latest data adjustment |
26 November 2022 |
