YM Uranus - IMO 9452763

Name

YM URANUS

Type

Oil tanker / Chemical tanker

IMO-number

9452763

Call sign

9HSQ9

Flag

Malta

Port of registry

Valletta

GT

4.829 t

DWT

6.970,2 t

NT

2.297 t

Length

119,10 m overall

111,60 m between perpendiculars

Breadth

16,90 m

Draught

6,80 m

Keel to mast end

33,60 m

Freeboard

1.684 mm

Depth

8,40 m moulded

Freeboard

1.684 mm

Speed

13,0 knots

Built

2008

Date of completion

05/11/2008

Builder

Marmara Shipyard

Istanbul

Turkey

Yard number

77

Hull material

Mild steel

Hull type

Double skin hull

Continuous decks

1

Main engine

1x MAN-B&W 6L32/40CD - 4 stroke 6 cylinder 320 x 400 mm combustion engine 3.000 kW / 4.076 hp at 750 rpm

Built: 20/02/2008

Builder: STX Engine Co., Ltd. - Korea

Propellers

1x Screw propeller controllable pitch - aft at 137 rpm

Rudder

Gurdesan flap rudder

Boilers

2x CHO 75,70 m² - 10,0 bar

1x CHR 59,20 m² - 10,0 bar

1x CHS 12,00 m² - 10,0 bar

Shaft generator

1x 1.265 kVA - 1.012 kW

Generators

3x MAN / Lindenberg diesel generatorsets each 606 kVA - 485 kW - 602 hp

Bow thruster

1x Jastram - 450 kW

Number of cargo tanks

12 + 2 slop tanks

Cargo capacity

Liquid: 8.050 m³

Slop capacity

160 m³

Number of pumps

12x Cargo pumps electrically driven submerged

pumps each 200 m³/h

2x Cargo pumps electrically driven submerged

pumps each 50 m³/h

Heating system

Thermal oil through 2x 2.000 kW

Thermal Boiler + 1x 1.000 Steam +1x 4.000 Butterworth

Tank capacities

Fuel oil: 357,78 m³

Diesel oil: 60 m³

Fresh water: 180 m³

Water ballast: 3.000 m³

Lifting equipment

1x Deck crane Gurdesan - SWL 5,0 t

Commercial manager

Solar Chartering Ltd.

Sogut Sokak 6, Orhantepe Mah, Kartal

34865 Istanbul

Turkey

ISM manager

Chemfleet

Sogut Sokak 6, Orhantepe Mah, Kartal

34865 Istanbul

Turkey

Registered owner

YM Uranus Tankers Limited

Care of Solar Chartering Ltd ,

Sogut Sokak 6, Orhantepe Mah, Kartal

34865 Istanbul

Turkey

Latest data adjustment

09 February 2023
