Westerschelde 28 August 2016 |
 |
|
| Westerschelde 28/02/16 | |
|
Name |
YUKON STAR |
|
Type |
Tanker for oil and chemicals |
|
IMO-number |
9411991 |
|
Call sign |
2BWW6 |
|
Flag |
Isle of Man - United Kingdom |
|
Port of registry |
Douglas |
|
GT |
23.312 t |
|
DWT |
Summer: 37.873 t |
|
NT |
9.972 t Panama: 19.419 t Suez: 20.874 t |
|
Length |
184,00 m overall 177,50 m between perpendiculars |
|
Breadth |
27,40 m moulded |
|
Draught |
11,51 m |
|
Keel to top mast |
43,93 m |
|
Depth |
17,20 m moulded |
|
Speed |
Service: 14,5 knots Max: 15,5 knots |
|
Built |
2008 |
|
Keel laid |
10/12/2008 |
|
Date of completion |
06/04/2009 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. Ulsan South Korea |
|
Yard number |
2096 |
|
Hull material |
Higher tensile steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 6S46MC -C - 2 stroke single acting 6 cylinder 460 x 1.932 mm combustion engine output Mcr 7.860 kW / 10.486 hp at 129,0 rpm Builder: Hyundai Heavy Industries Co Ltd - South Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 129,0 rpm |
|
Boilers |
1x Exhaust gas eEconomiser 1x Water tube auxiliary boiler |
|
Generators |
3x Hyundai Himsen 5H21/32 - 4 stroke 5 cylinder 210 x 320 mm diesel engine each Mcr 780 kW connected with generators each 730 kW / 450 Volt 60 Hz Builder: Hyundai Heavy Industries Co Ltd - South Korea |
|
Number of cargo tanks |
12 |
|
Total cargo capacity 98 % |
Tank 1 Port & stb: 2.583,4 m³ each Tank 2 Port & stb: 3.641,9 m³ each Tank 3 Port & stb: 3.710,3 m³ each Tank 4 Port & stb: 3.710,3 m³ each Tank 5 Port & stb: 3.710,3 m³ each Tank 6 Port & stb: 3.439,1 m³ each Total: 42.630 m³ incl. slop tanks 268.134 bbls |
|
Number of slop tanks |
2 |
|
Slop tank capacity |
Tanks Port & stb: 536,4 m³ each |
|
Number of segregations |
6 + 1 |
|
Number of pumps |
10x Framo Deepwell pumps each 500 m³/h 2x Framo Deepwell pumps each 300 m³/h 2x Framo Deepwell Pumps each 200 m³/h |
|
Pumping capacity |
abt. 2.500 m³/h |
|
Loading capacity |
abt. 3.000 m³/h |
|
Tank coating |
Phenolic epoxy |
|
Manifolds |
Bow to centre of manifold: 92,16 m |
|
Tank capacities |
HFO: 1.100 m³ Diesel oil: 170 m³ Ballast: 18.100 m³ |
|
Lifting equipment |
1x Hose crane - SWL 10,0 t |
|
Crew size |
19 |
|
Manager |
Rigel Schiffahrts GmbH & Co. KG Domshof 14 28195 Bremen Germany |
|
Previous owners |
Rigel Reederei GmbH & Co. KG MT "Yukon Star" |
|
Renamed |
2019 Inviken Liberia, Monrovia - Call sign: D5RF4 2023 Flamenco Liberia, Monrovia - Call sign: D5RF4 Manager: Trafigura Maritime Logistics - Republic of Singapore Owner: Inviken AS |
|
Latest data adjustment |
15 June 2023 |
