Westerschelde 16 September 2017 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 17/03/12 | Westerschelde 17/03/12 | Vlissingen 12/11/12 | Westerschelde 21/09/17 | Westerschelde 04/03/19 | Westerschelde 19/05/15 | |||||
|
Name |
EVINCO |
|
Type |
Tanker for oil and chemicals |
|
IMO-number |
9308546 |
|
Call sign |
SFZX |
|
Flag |
Sweden |
|
Port of registry |
Donsö |
|
GT |
13.769 |
|
DWT |
Summer: 19.999 t |
|
NT |
6.521 t |
|
Length |
155,47 m overall 140,00 m between perpendiculars |
|
Breadth |
27,73 m extreme |
|
Draught |
9,78 m |
|
Depth |
12,80 m moulded |
|
Speed |
Service: 14,5 knots |
|
Built |
2005 |
|
Keel laid |
16/11/2004 |
|
Launch date |
06/04/2005 |
|
Date of completion |
19/09/2005 |
|
Builder |
Shanghai Edward Shipbuilding Co., Ltd 1 Nan Ma Tou Road Pudong New Area 200125 Shanghai China |
|
Yard number |
H132 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Bulkheads |
Transverse: 9 Longitudinal: 3 |
|
Main engine |
3x Wärtsilä W6L32CR 1x Wärtsilä 4L20 Total: 9.720 KW |
|
Propulsion |
1x Siemens / Schottel - 5.800 kW |
|
Boilers |
4x Thermal oil heater, exhaust heated EGH200V40 2x Thermal oil heater, oil fired TOH3800V50 |
|
Generators |
2x Wärtsilä 6L32 CR diesel generatorsets 1x Wärtsilä 6L32 CR generatorset 1x Wärtsilä 4L20 generatorset Builder: Wärtsilä Finland Oy |
|
Emergency generator |
1x Volvo Penta D25A diesel generatorset 450kW |
|
Bow thruster |
1x 900 kW |
|
Number of tanks |
7 |
|
Cargo tank capacity |
22.659 m³ |
|
Pumps |
14x Pres-Vac cargo pumps each 250 m³/h |
|
Tank capacities |
Ballast: 8.107,10 m³ |
|
Manager |
Rederi AB Donsötank Donsö Hamnväg 18 SE-430 82 Donsö Sweden |
|
Operator |
Rederi AB Donsotank |
|
Registered owner |
Donsö Shipping AB Donsö Hamnväg 18 SE-430 82 Donsö Sweden |
|
Latest data adjustment |
03 January 2021 |
