| Antwerpen 22 May 2013 |
 |
 |
 |
 |
 |
 |
|||||
| Antwerpen 22/05/13 | Deurne 14/07/14 | Deurne 14/07/14 | Merksem 30/07/14 | Merksem 30/07/14 | Antwerpen 09/09/16 | |||||
|
Name |
SOMTRANS XXI |
|
Type |
Inland tanker |
|
ENI-number |
02333400 |
|
Flag |
G.D. Luxembourg |
|
Port of registry |
Stadtbredimus |
|
DWT |
4.296 t |
|
Length |
135,00 m |
|
Breadth |
11,40 m |
|
Draught |
3,80 m |
|
Depth |
4,16 m |
|
Built |
2009 |
|
Builder casco |
Sainty Marine |
|
Builder completion |
Jac. den Breejen |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
2x Caterpillar3508 (C) DI-TA electronic each 1.065 hp / 783 kW at 1.600 rpm |
|
Propellers |
2x Propellers with nozzle Giessen Optima - diameter: 1.714 mm |
|
Gearbox |
2x Masson Marine type MM W5200 - reduction: 4,962:1 |
|
Bow thruster |
1x Caterpillar - Verhaar Omega-Jet - 580 hp / 426 kW at 1.780 rpm |
|
Pumps |
14x Marflex deepwell type MDPE-80 cargo pumps each 80 m³/h 1x Marflex deepwell ballast pump type MBDPC-200 - 650 m³/h |
|
Pump capacity |
1.120 m³/h |
|
Tank capacity 100% |
5.159 m³ |
|
Anchor equipment |
1x Hydraulic car crane - SWL 1.750 kg - Outreach 18,00 m |
|
Operator |
Somtrans NV Albertkanaalbaan 9 |
|
Owner |
Somtralux SA |
|
Latest data adjustment |
05 January 2015 |
