Name |
LIESEL ESSBERGER |
Previous names |
2004 - 08.2008 Cape Everad 2008 - 06/2011 UCT Everad |
Type |
Chemical / Oil products tanker |
IMO-number |
9272761 |
Call sign |
CQLN |
Flag |
Portugal |
Port of registry |
Madeira |
GT |
5.955 t |
DWT |
8.545 t |
NT |
2.533 t |
Length |
118,00 m overall 111,06 m registered |
Breadth |
18,80 m registered |
Draught |
7,35 m |
Keel to mast end |
34,40 m |
Depth |
9,70 m moulded |
Speed |
14,0 knots |
Built |
2004 |
Keel laid |
10/10/2003 |
Launch date |
10/02/2004 |
Date of completion |
31/05/2004 |
Builder |
Sasaki Shipbuilding Co., Ltd. 65-1, Kinoe, Osakikamijima-ch Toyota-gun Kinoe ,725-0401 Hiroshima-ken Japan |
Yard number |
648 |
Hull material |
Shipbuilding steel (standard) |
Hull type |
Double bottom, continuous from peak to peak bulkhead |
Watertight bulkheads |
11 |
Continuous decks |
1 |
Main engine |
1x Hitachi/MAN-B&W 6S35MC - 2 stroke 6 cylinder 350 x 1.400 mm combustion engine 4.440 kW / 6.060 hp at 173 rpm Year of Manufacture: 2003 Manufacturer: Hitachi Zosen Corporation Sakurajima Works 7-89, Nanko-kita 1-chome Suminoe-ku Osaka ,559-8559 Osaka-fu Japan |
Propellers |
1x Fixed pitch propeller - aft at 173 rpm |
Boilers |
1x Steam boiler, oil fired - 10,0 bar Heating surface: 10,0 m² 1xSteam boiler, exhaust gas heated - 10,0 bar Heating surface: 60,0m² 1x Steam boiler, oil fired - 10,0 bar Heating surface: 81,0 m² Year of Manufacture: 2003 Manufacturer: Alfa Laval Qingdao Ltd. 86 Guangzhou Road North Jiaozhou Qingdao ,266300 Shandong People's Republic of China |
Electric installations |
3x Plants each 440 V - 700 kVA 1x Plant 440 V - 65 kVA |
Generators |
3x Yanmar N18AL-SV main diesel generatorsets each 700 kVA |
Emergency generator |
1x Deutz F6L912 diesel generatorset 65 kVA |
Compressed air receivers |
2x Receivers each 1200 litres - 30,0 bar 1x Receiver 150 litres - 30,0 bar |
Thruster |
1x 475 kW - aft 1x 475 kW - forward |
Number of cargo tanks |
18 |
Cargo tank capacity |
Liquid: 9.083 m³ |
Number of pumps |
10x Cargo pumps each 300 m³/h 4x Cargo pumps each 200 m³/h 4x Cargo pumps each 100 m³/h |
Tank capacities |
Fuel capacity: 612 m³ |
Anchor equipment |
3x Anchors weight each 3.540 kg Chain length: 522,50 m Diameter: 52 mm |
Crew size |
17 |
ISM & commercial manager |
John T. Essberger GmbH & Co. KG Palmaille 45 22767 Hamburg Federal Republic of Germany |
Registered owner |
"LIESEL ESSBERGER" Tankreederei GmbH & Co. KG Palmaille 45 22767 Hamburg Federal Republic of Germany |
Latest data adjustment |
10 March 2022 |
