Name |
SUNDSTRAUM |
|
Previous names |
02/1993 - 08/1996 Maj Britt Terkol |
|
Type |
Chemical and product tanker |
|
IMO-number |
8920567 |
|
Call sign |
LIFL3 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
GT |
3.206 t |
|
DWT |
Summer: 4.737 t |
|
NT |
1.358 t |
|
Length |
96,35 m overall 88,25 m between perpendiculars |
|
Breadth |
15,33 m extreme |
|
Draught |
6,21 |
|
Keel to masthead |
40,00 m 31,50 m in collapsed condition |
|
Depth |
8,05 m moulded |
|
Speed |
13,2 knots |
|
Built |
1993 |
|
Keel laid |
23/06/1992 |
|
Launch date |
03/10/1992 |
|
Date of completion |
02/03/1993 |
|
Builder |
Euroflex Marine (Århus Flydedok A/S) Aarhus Denmark |
|
Yard number |
202 |
|
Hull material |
Steel |
|
Hull type |
Double bottom Double side |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 9M453C - 4 stroke 9 cylinder combustion engine 2.970 kW / 4.038 hp Builder: Krupp MaK Motoren GmbH & Co.KG, Kiel - Germany |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Thermal oil heater, exhaust heated - Extrac D/FL/536 2x Thermal oil heater, oil fired - Thermopac 1000R |
|
Shaft generator |
1x 633 kW |
|
Generators |
3x MTU 12V 183 TE52 diesel generatorsets each 335 kW |
|
Bow thruster |
1x 313 kW |
|
Number of tanks |
12 |
|
Tank capacity 98% |
Tank 1: P: 310,2 m³ / S: 209,0 m³ Tank 2: P: 365,1 m³ / S: 365,3 m³ Tank 3: P: 366,2 m³ / S: 366,5 m³ Tank 4: P: 363,8 m³ / S: 368,9 m³ Tank 5: P: 365,5 m³ / S: 366,5 m³ Tank 6: P: 343,0 m³ / S: 343,7 m³ Total: 4.859,7 m³ incl slop tanks |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
Tanks P/ 101,3 m³ / S: 98,0 m³ |
|
Manifolds |
Bow to centre manifold: 49,70 m Stern to centre manifold: 46,65 m Distance bridge front to centre of manifold: 25,00 m |
|
Tank capacities |
Water ballast: 1.791,1 m³ |
|
Anchor equipment |
Length 467,5 m Diameter: 46 mm |
|
Manager |
Utkilen AS Bergen Norway |
|
Previous managers |
1993 - 2007 Utkilen AS 2007 - 2008 OSM Ship Management AS 2008 - 2008 Fleet Ship Management Pte., Ltd. 2008 - 2008 Fleet Management Europe Ltd. 2008 - 2008 Fleet Management Limited 2008 - 2009 Fleet Management Europe Ltd. |
|
Owner |
Utkilen Shipping AS Strandgaten 197 Bergen Norway |
|
Previous owners |
1993 - 2001 K/S A/S Fostraum 2001 - 2006 EGD Shipping III AS 2006 - 2007 Sundstraum II AS |
|
Renamed |
2019 Key Sund Norway, Bergen - Call sign: LIFL3 Manager: Fjord Shipping AS Reg. Owner: Key Tankers AS |
|
Latest data adjustment |
20 October 2020 |
