Westerschelde 23 December 2019 |
 |
 |
 |
||
| Westerschelde 23/12/19 | Westerschelde 23/12/19 | Vlissingen 25/05/19 | ||
|
Name |
SUN PLOEG |
|
Type |
Chemical tanker and oil tanker |
|
IMO-number |
9724439 |
|
Call sign |
ZGER6 |
|
Flag |
Cayman Islands |
|
Port of registry |
George Town |
|
GT |
12.085 t registered Suez: 12.397,48 t |
|
DWT |
Summer: 19.975,38 m Winter: 19.373,78 t |
|
NT |
6.306 t registered Suez: 10.632,13 t Panama: 10.163,00 t |
|
Displacement |
Summer: 26.613,77 t Winter: 25.012,17 t |
|
Length |
146,50 m overall |
|
Breadth |
24,03 m extreme |
|
Draught |
Summer: 9,76 m Winter: 9,56 m |
|
Moulded L x B x D |
138,00 x 24,00 x 13,10 m |
|
Registered L x B x D |
138,44 x 24,00 x 13,10 m |
|
Keel to masthead |
38,57 m |
|
Air draft |
Summer deadweight: 28,81 m Normal ballast: 31,83 m Lightship: 36,11 m |
|
Freeboard |
Summer: 3.374 mm Winter: 3.580 mm |
|
Depth |
13,10 m moulded |
|
Speed |
14,0 knots laden 12,0 knots economic laden |
|
Built |
2015 |
|
Keel laid |
08/10/2008 |
|
Launch date |
20/02/2015 |
|
Date of completion |
29/05/2015 |
|
Builder |
Fukuoka Shipbuilding Co Ltd. Japan |
|
Yard number |
F-1306 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W/Makita 6S42MC7.1 - 2 stroke single acting 6 cylinder 420 x 1.764 mm combustion engine 4.440 kW at 117,0 rpm Manufacturer: Makita Corporation |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 390 mm |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary vertical boiler - 9,3 bar Evaporation: 15,95 t/h Manufacturer: Tortoise Engineering Co., Ltd. |
|
Generators |
3x Yanmar 6EY18ALW min diesel generatorsets each 560 kW |
|
Bow thruster |
871,5 bhp |
|
Number of cargo tanks |
20 |
|
Cargo tank capacity 98% |
20.673,24 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
1.160,27 m³ |
|
Pumps |
2x Centrifugal ballast pumps each 250 m³/h 12x Centrifugal cargo pumps each 300 m³/h 8x Centrifugal cargo pumps each 200 m³/h |
|
Manifolds |
Distance bridge front to centre of manifold: 43,40 m Bow to centre manifold: 75,60 m Stern to centre manifold: 70,90 m Distance between cargo manifold centres: 400 mm Distance ships rail to manifold: 4.400 mm Distance manifold to ships side: 4.600 mm Top of rail to centre of manifold: 690 mm Distance main deck to centre of manifold: 2/331 mm Spill tank grating to centre of manifold: 910 mm |
|
Tank capacities |
Fuel oil: 759,75 m³ Gas oil: 233,53 m³ Fresh water: 232,42 m³ |
|
Lifting equipment |
1x Crane - SWL 10,0 t |
|
Technical operator |
Diamond Ship Management Pte. Ltd. 460 Alexandra Road, #31-01 PSA Building Singapore 119963 Republic of Singapore |
|
Commerical operator |
Hansa Tankers AS Kalfarveien 57A 5022 Bergen Norway |
|
Registered owner |
Inventor Chemical Tankers AS Kalfarveien 57A 5022 Bergen Norway |
|
Disponent owner |
Hansa Tankers AS Kalfarveien 57A 5022 Bergen Norway |
|
Latest data adjustment |
01 September 2021 |
