Westerschelde 11 March 2019 |
 |
 |
|
| Westerschelde 24/07/17 | Antwerpen 07/03/14 | |
|
Name |
KARINA THERESA |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9428451 |
|
Call sign |
OUPL2 |
|
Flag |
Denmark |
|
Port of registry |
Herning |
|
GT |
5.706 t |
|
DWT |
Summer: 7.871,42 t Winter: 7.604,10 t |
|
NT |
2.406 t |
|
Length |
101,39 m overall 94,96 m between perpendiculars |
|
Breadth |
19,05 m |
|
Draught |
Summer: 7,60 m |
|
Keel to mast end |
33,83 m |
|
Air draft |
27,64 m |
|
Freeboard |
2.911 mm |
|
Depth |
10,50 m |
|
Speed |
14,0 knots |
|
Built |
2009 |
|
Date of completion |
24/03/2009 |
|
Builder |
Nantong Mingde Heavy Industry Stock Co.,Ltd. Nantong China |
|
Yard number |
MD042-8000DWT-04 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
61 |
|
Continuous decks |
1 |
|
Main engine |
1x Bergen B32:40L8P - 4 stroke 8 cylinder 320 x 400 mm combustion engine 4.000 kW / 5.435 hp at 750 rpm Built: 02/2008 Builder: Rolls-Royce Marine AS, Hordvikneset 125, 5108 Hordvik - Norway |
|
Propellers |
1x Screw propeller controllable pitch |
|
Boilers |
1x CHM Aaborg 133,00 m² - 9,0 bar 1x CHO Aalborg 49,90 m² - 9,0 bar |
|
Shaft generator |
1x 1.350 kVA - 1.080 kW |
|
Generators |
3x Scania diesel engines connected with Nordhavn generators each 525 kVA - 420 kW - 611 hp |
|
Emergency generator |
1x Diesel generatorset 124 kVA - 99 kW - 177 hp |
|
Bow thruster |
1x Nakashima 400 kW |
|
Number of tanks |
12 |
|
Total capacity of cargo tanks |
9.067 m³ at 98% filling in 10 marine line cargo tanks & + 2 Deck Cargo/Slop tanks each 46,2 m³ at 98% filling |
|
Segregation |
5x Double valve segregations with 5 common lines |
|
Cargo pumps |
8x Cargo pumps 200 m³/h 2x Cargo pumps 175 m³/h 1x Cargo pump 100 m³/h |
|
Loading rate |
2.000 m³/h |
|
Discharging rate |
1.000 m³/h |
|
Heating capacity |
Steam heating, max. load/discharge temp 80°C |
|
Manifolds |
Manifold to main deck: 2.000 mm Manifold to platform: 700 mm Manifold to stern: 47,87 m Manifold to bow: 48,62 m Manifold to rail: 2.650 mm |
|
Tank capacities |
Fuel oil: 472,1 m³ Diesel oil: 54,9 m³ Water ballast: 3.100 m³ |
|
Lifting equipment |
1x Deck cranes - SWL 3,0 t 1x Deck crane - SWL 15,0 t |
|
Commercial manager |
Christiania Shipping A/S Amerika Plads 38 2100 Copenhagen Denmark |
|
Technical manager |
TB Marine Shipmanagement (Riga), Branch Office of Christiania Shipping A/S 17a Duntes Str. LV-1005 Riga Latvia |
|
Registered owner |
Christiania Shipping A/S Amerika Plads 38 2100 Copenhagen Denmark |
|
Latest data adjustment |
24 July 2022 |
